2-52 ALPS Advanced Line Protection System
GE Power Management
2.5 REFERENCE TABLES 2 CALCULATION OF SETTINGS
2
Table 2–10: INDEX NUMBERS –
SCHEME, RECLOSER, & PROGRAMMABLE LOGIC
(Sheet 1 of 5)
ALPS with Single Phase Tripping ALPS with Three Phase Tripping
Index Description Mnemonic Index Description Mnemonic
33 Trip Bus Phase A TRIPA 33 Trip Bus TRIP
34 Trip Bus Phase B TRIPB 34 Spare
35 Trip Bus Phase C TRIPC 35 Spare
36 1P Reclose Initiate RI-1P 36 Spare
37 3P Reclose Initiate RI-3P 37 3P Reclose Initiate RI
38 Reclose Cancel Output from Scheme
Lo
g
ic
CANCL 38 Reclose Cancel Output from Scheme
Lo
g
ic
CANCL
39 KEY XMTR1/CARR START Output from
Scheme Lo
g
ic
KEY1 39 KEY XMTR1/CARR START Output from
Scheme Lo
g
ic
KEY1
40 KEY XMTR2/CARR STOP Output from
Scheme Lo
g
ic
KEY2 40 KEY XMTR2/CARR STOP Output from
Scheme Lo
g
ic
KEY2
41 3 Phase Trip Enable TRIP3P 41 Spare
42 Spare 42 Spare
43 Spare 43 Warm Restart WARMST
44 Reclose in Pro
g
ress RIP 44 Reclose in Pro
g
ress RIP
45 Line Over Load Alarm Output LNOVLD 45 Line Over Load Alarm Output LNOVLD
46 Critical Alarm Output CRTALM 46 Critical Alarm Output CRTALM
47 Recloser Lockout Alarm LORCL 47 Recloser Lockout Alarm LORCL
48 Trip Circuit Alarm TCMALM 48 Trip Circuit Alarm TCMALM
49 Zone Fla
g
s On Alarm ZNALM 49 Zone Fla
g
s On Alarm ZNALM
50 Overcurrent Alarm OVRALM 50 Overcurrent Alarm OVRALM
51 Unbalanced Current Detector Alarm
Output
UNBAL 51 Unbalanced Current Detector Alarm
Output
UNBAL
52 Non-Critical Alarm Output NCALM 52 Non-Critical Alarm Output NCALM
53 Spare 53 Key 3
54 Spare 54 Key 4
55 Spare 55 Spare
56 MANUAL OPEN BRK1 MNOPN1 56 MANUAL OPEN BRK1 MNOPN1
57 MANUAL OPEN BRK2 MNOPN2 57 MANUAL OPEN BRK2 MNOPN2
58 MANUAL CLOSE BRK1 MNCLS1 58 MANUAL CLOSE BRK1 MNCLS1
59 MANUAL CLOSE BRK2 MNCLS2 59 MANUAL CLOSE BRK2 MNCLS2
60 Fault ID: Phase A Involved DAFLTA 60 Fault ID: Phase A Involved DAFLTA
61 Fault ID: Phase B Involved DAFLTB 61 Fault ID: Phase B Involved DAFLTB
62 Fault ID: Phase C Involved DAFLTC 62 Fault ID: Phase C Involved DAFLTC
63 Fault ID: Neutral Involved DAFLTN 63 Fault ID: Neutral Involved DAFLTN
64 DMA Overrun DMAOVR 64 DMA Overrun DMAOVR
65 Zone 1 AB Distance Function Z1AB 65 Zone 1 AB Distance Function Z1AB
66 Zone 1 BC Distance Function Z1BC 66 Zone 1 BC Distance Function Z1BC
67 Zone 1 CA Distance Function Z1CA 67 Zone 1 CA Distance Function Z1CA
68 Zone 2 AB Distance Function Z2AB 68 Zone 2 AB Distance Function Z2AB
69 Zone 2 BC Distance Function Z2BC 69 Zone 2 BC Distance Function Z2BC
70 Zone 2 CA Distance Function Z2CA 70 Zone 2 CA Distance Function Z2CA
71 Zone 3 AB Distance Function Z3AB 71 Zone 3 AB Distance Function Z3AB
72 Zone 3 BC Distance Function Z3BC 72 Zone 3 BC Distance Function Z3BC
73 Zone 3 CA Distance Function Z3CA 73 Zone 3 CA Distance Function Z3CA
74 Zone 4 AB Distance Function Z4AB 74 Zone 4 AB Distance Function Z4AB
75 Zone 4 BC Distance Function Z4BC 75 Zone 4 BC Distance Function Z4BC
