GE Power Management
ALPS Advanced Line Protection System 2-53
2 CALCULATION OF SETTINGS 2.5 REFERENCE TABLES
2
76 Zone 4 CA Distance Function Z4CA 76 Zone 4 CA Distance Function Z4CA
77 Any Z1 Phase Distance Function Z1PH 77 Any Z1 Phase Distance Function Z1PH
78 Any Z2 Phase Distance Function Z2PH 78 Any Z2 Phase Distance Function Z2PH
79 Any Z3 Phase Distance Function Z3PH 79 Any Z3 Phase Distance Function Z3PH
80 Any Z4 Phase Distance Function Z4PH 80 Any Z4 Phase Distance Function Z4PH
81 Zone 1 AG Distance Function Z1AG 81 Zone 1 AG Distance Function Z1AG
82 Zone 1 BG Distance Function Z1BG 82 Zone 1 BG Distance Function Z1BG
83 Zone 1 CG Distance Function Z1CG 83 Zone 1 CG Distance Function Z1CG
84 Zone 2 AG Distance Function Z2AG 84 Zone 2 AG Distance Function Z2AG
85 Zone 2 BG Distance Function Z2BG 85 Zone 2 BG Distance Function Z2BG
86 Zone 2 CG Distance Function Z2CG 86 Zone 2 CG Distance Function Z2CG
87 Zone 3 AG Distance Function Z3AG 87 Zone 3 AG Distance Function Z3AG
88 Zone 3 BG Distance Function Z3BG 88 Zone 3 BG Distance Function Z3BG
89 Zone 3 CG Distance Function Z3CG 89 Zone 3 CG Distance Function Z3CG
90 Zone 4 AG Distance Function Z3AG 90 Zone 4 AG Distance Function Z3AG
91 Zone 4 BG Distance Function Z4BG 91 Zone 4 BG Distance Function Z4BG
92 Zone 4 CG Distance Function Z4CG 92 Zone 4 CG Distance Function Z4CG
93 Any Z1 Ground Distance Function Z1GRD 93 Any Z1 Ground Distance Function Z1GRD
94 Any Z2 Ground Distance Function Z2GRD 94 Any Z2 Ground Distance Function Z2GRD
95 Any Z3 Ground Distance Function Z3GRD 95 Any Z3 Ground Distance Function Z3GRD
96 Any Z4 Ground Distance Function Z4GRD 96 Any Z4 Ground Distance Function Z4GRD
97 Phase A Open AOPEN 97 Spare
98 Phase B Open BOPEN 98 Spare
99 Phase C Open COPEN 99 Spare
100 All Phases Open 3OPEN 100 All Phases Open 3OPEN
101 Any Phases Open ANYOPN 101 Any Phases Open ANYOPN
102 1 Pole Open 1OPEN 102 Spare
103 Any Phase Undervolta
g
e ANYUVT 103 Any Phase Undervolta
g
e ANYUVT
104 All Volta
g
es Hi
g
h (No Phase
Undervolta
g
e)
ALLVLT 104 All Volta
g
es Hi
g
h (No Phase
Undervolta
g
e)
ALLVLT
105 Fault Detector (FD) FLTDET 105 Fault Detector (FD) FLTDET
106 TL1 Timer Output TL1 106 TL1 Timer Output TL1
107 IT Detector IT 107 IT Detector IT
108 IB Detector IB 108 IB Detector IB
109 IPT Detector IPT 109 IPT Detector IPT
110 IPB Detector IPB 110 IPB Detector IPB
111 Remote Breaker Open Detector REMOPN 111 Remote Breaker Open Detector REMOPN
112 Ground Directional Trip (NT·IPT) GRDTRP 112 Ground Directional Trip (NT·IPT) GRDTRP
113 Ground Directional Block (NB·IPB) GRDBLK 113 Ground Directional Block (NB·IPB) GRDBLK
114 Line Pickup LPU 114 Line Pickup LPU
115 Fuse Failure Alarm FF 115 Fuse Failure Alarm FF
116 Instantaneous Phase O/C (50P/PH4) 50 116 Instantaneous Phase O/C (50P/PH4) 50
117 Instantaneous Ground O/C (50G/IDT) 50G 117 Instantaneous Ground O/C (50
g
/IDT) 50G
118 Ground Time Overcurrent Pick Up TOCACT 118 Ground Time Overcurrent Pick Up TOCACT
119 Ground Time Overcurrent Trip (51G/TOC) TOCTRP 119 Ground Time Overcurrent Trip (51G/TOC) TOCTRP
120 Out of Step Blockin
g
OSB 120 Out of Step Blockin
g
OSB
121 Out of Step Trip OST 121 Out of Step Trip OST
Table 2–10: INDEX NUMBERS –
SCHEME, RECLOSER, & PROGRAMMABLE LOGIC
(Sheet 2 of 5)
ALPS with Single Phase Tripping ALPS with Three Phase Tripping
Index Description Mnemonic Index Description Mnemonic
