8-20 ALPS Advanced Line Protection System
GE Power Management
8.2 INFORMATION 8 LOCAL USER INTERFACE
8
• Trip A signal ON
• Trip A signal reset
• Trip B signal ON
• Trip B signal reset
• Trip C signal ON
• Trip C signal reset
• Out of step block ON
• Out of step block OFF
• Breaker #1 open
• Breaker #1 closed
• Breaker #2 open
• Breaker #2 closed
• Fuse failure alarm ON
• Fuse failure alarm OFF
• Receive carrier ON
• Receive carrier OFF
• Key transmitter ON
• Key transmitter OFF
• Trip circuit #1 energized
• Trip circuit #2 energized
• Trip circuit #3 energized
• Trip circuit #4 energized
• Trip circuit #5 energized
• Trip circuit #6 energized
• Line overload alarm ON
• Line overload alarm OFF
• Trip circuit #1 monitor alarm ON
• Trip circuit #1 monitor alarm OFF
• Trip circuit #2 monitor alarm ON
• Trip circuit #2 monitor alarm OFF
• Trip circuit #3 monitor alarm ON
• Trip circuit #3 monitor alarm OFF
• Trip circuit #4 monitor alarm ON
• Trip circuit #4 monitor alarm OFF
• Trip circuit #5 monitor alarm ON
• Trip circuit #5 monitor alarm OFF
• Trip circuit #6 monitor alarm ON
• Trip circuit #6 monitor alarm OFF
• Pilot protection ON
• Pilot protection OFF
• Oscillography trigger
• Fail: Trip bus check
• Unbalanced system detection alarm ON
• Unbalanced system detection alarm OFF
• Zone measurement units alarm ON
• Zone measurement units alarm OFF
• Overcurrent monitor alarm ON
• Overcurrent monitor alarm OFF
• Trip circuit #1 not energized
• Trip circuit #2 not energized
• Trip circuit #3 not energized
• Trip circuit #4 not energized
• Trip circuit #5 not energized
• Trip circuit #6 not energized
• Manual recloser lockout ON
• TOC curve changed
• Runtime NO DMA interrupt
• Manual recloser lockout OFF
• External reclose initiate - 1P
• External reclose initiate - 3P
• External recloser reset
• Recloser lockout - reclose cancel
• Reclose lockout - breaker failure
• Out of step trip ON
• Out of step trip OFF
• Run time ANI controller error
• Run time ANI reference error
• Run time DSP H/W fail
• Run time DSP settings error
• Run time DSP table corrupted
• Recloser in reset
• Recloser in progress start
• Recloser in progress end
• Recloser Three Pole Cycle 1
• Recloser Three Pole Cycle 2
• Recloser Three Pole Cycle 3
• Recloser Three Pole Cycle 4
• RECL in Lockout No Sync Check
• RECL in Lockout No Inhibit Input
• RECL in Lockout Breaker Open
• RECL in Lockout REC Unsuccessful
• RECL in Lockout Reclose Cancel
• RECL in Lockout BRK Fail to Open
• RECL in Lockout Maximum Shots
• RECL in Lockout Invalid REC Type
• RECLOSE Output Issued
• RECL in Lockout Manual Lockout
An example of event information display is shown below:
13:45:21.240 Evt#100
09/12/88
LUI:MANUAL CLOSE
