GE ALPS - Page 314

B-20 ALPS Advanced Line Protection System
GE Power Management
B.2 REGISTER MAPS APPENDIX B
B
F61
ctd
139 TRIP CIRCUIT #4 MONITOR
ALARM ON
140 TRIP CIRCUIT #4 MONITOR
ALARM OFF
141 TRIP CIRCUIT #5 MONITOR
ALARM ON
142 TRIP CIRCUIT #5 MONITOR
ALARM OFF
143 TRIP CIRCUIT #6 MONITOR
ALARM ON
144 TRIP CIRCUIT #6 MONITOR
ALARM OFF
145 PILOT PROTECTION ON
146 PILOT PROTECTION OFF
147 OSCILLOGRAPHY TRIGGERED
148 FAIL-TRIP BUS CHECK
149 UNBALANCED SYSTEM
DETECTION ALARM ON
150 UNBALANCED SYSTEM
DETECTION ALARM OFF
151 ZONE MEASUREMENT UNITS
ALARM ON
152 ZONE MEASUREMENT UNITS
ALARM OFF
153 OVERCURRENT MONITOR
ALARM ON
154 OVERCURRENT MONITOR
ALARM OFF
155 TRIP CIRCUIT #1 NOT
ENERGIZED
156 TRIP CIRCUIT #2 NOT
ENERGIZED
157 TRIP CIRCUIT #3 NOT
ENERGIZED
158 TRIP CIRCUIT #4 NOT
ENERGIZED
159 TRIP CIRCUIT #5 NOT
ENERGIZED
160 TRIP CIRCUIT #6 NOT
ENERGIZED
161 Recloser in Reset
162 Reclose In Pro
g
ress - Start
163 Reclose In Pro
g
ress - End
164 Sin
g
le Pole Reclose - Shot1
165 Sin
g
le Pole Reclose - Shot2
166 Sin
g
le Pole Reclose - Shot3
167 Sin
g
le Pole Reclose - Shot4
168 Three Pole Reclose - Shot1
169 Three Pole Reclose - Shot2
170 Three Pole Reclose - Shot3
171 Three Pole Reclose - Shot4
172 OUT OF STEP TRIP ON
173 OUT OF STEP TRIP OFF
Table B–5: DATA FORMATS (Sheet 11 of 12)
TYPE VALUE/
BITMASK
DESCRIPTION
F61
ctd
174 RUNTIME ANI CONTROL ERROR
175 RUNTIME ANI REFERENCE
ERROR
176 TOC Curve Chan
g
ed
177 Run time DSP handshake
178 Run time DSP PROGRAM ROM
179 Run time DSP STATIC RAM
180 Run time DSP CRC STATIC RAM
181 Run time DSP DPRAM
182 Run time DSP DPRAM
CHECKSUM
183 Run time NO DMA interrupt
184 EEPROM CRC Recalculated
185 Max Breaker operations exceeded
186 Max I2T exceeded
187 No Sync Check
188 Recloser in Lockout - No Inhibit
Input
189 Recloser in Lockout - Breaker open
190 Recloser in Lockout - Reclose
Unsuccessful
191 Recloser in Lockout - Reclose
Cancel
192 Recloser in Lockout - Breaker Fail
to open
193 Recloser in Lockout - Maximum
Shots
194 Recloser in Lockout - Invalid
Reclose Type
195 Reclose - Output Issued
196 Recloser in Lockout - Manual
Lockout
F69 2 bytes Event Source
0Port PL1
1Port PL2
2Port PL3
3LUI
4Protection
5Self Test
6 Start Up
P10 2 bytes Integer Fixed Point, 1 Decimal
Field Value is multiplied by 10
P100 2 bytes Integer Fixed Point, 2 Decimals
Field Value is multiplied by 100
Table B–5: DATA FORMATS (Sheet 12 of 12)
TYPE VALUE/
BITMASK
DESCRIPTION
