GE Power Management
ALPS Advanced Line Protection System C-9
APPENDIX C C.3 POINT LISTS
C
129 Any Phase Overvolta
g
e Class 1
130 I1 Line Pickup Class 1
131 Manual Close Requested Class 1
132 CC Input – 52b Breaker #1 Phase A Class 1
133 CC Input – 52b Breaker #1 Phase B Class 1
134 CC Input – 52b Breaker #1 Phase C Class 1
135 CC Input – 52b Breaker #2 Phase A Class 1
136 CC Input – 52b Breaker #2 Phase B Class 1
137 CC Input – 52b Breaker #2 Phase C Class 1
138 CC Input – Enable 3-Phase Trippin
g
Class 1
139 CC Input – Chan
g
e Settin
g
Group Input Bit 0 Class 1
140 CC Input – Chan
g
e Settin
g
Group Input Bit 1 Class 1
141 CC Input – Stop Carrier / Receiver 3 Class 1
142 CC Input – Block Pilot Trippin
g
/Receiver 4 Class 1
143 CC Input – Receiver 1 Class 1
144 CC Input – Receiver 2 Class 1
145 CC Input – Sin
g
le Pole Reclose Initiate Class 1
146 CC Input – Three Pole Reclose Initiate Class 1
147 CC Input – Reclose Inhibit Class 1
148 CC Input – Reclose Cancel Class 1
149 CC Input – Reclose Reset Class 1
150 CC Input – Manual Close Class 1
151 CC Input – Tar
g
et Reset Class 1
152 CC Input – Disable Protection Class 1
153 CC Input – Disable Outputs Class 1
154 CC Input – Oscillo
g
raphy Tri
gg
er Class 1
155 CC Input – Manual Lockout Class 1
156 CC Input – Confi
g
urable Input 1 Class 1
157 CC Input – Confi
g
urable Input 2 Class 1
158 CC Input – Confi
g
urable Input 3 Class 1
159 CC Input – Confi
g
urable Input 4 Class 1
160 CC Input – Confi
g
urable Input 5 Class 1
161 CC Input – Confi
g
urable Input 6 Class 1
162 CC Input – Confi
g
urable Input 7 Class 1
163 CC Input – Confi
g
urable Input 8 Class 1
164 CC Input #1 Closed Class 1
165 CC Input #2 Closed Class 1
166 CC Input #3 Closed Class 1
167 CC Input #4 Closed Class 1
168 CC Input #5 Closed Class 1
169 CC Input #6 Closed Class 1
170 CC Input #7 Closed Class 1
171 CC Input #8 Closed Class 1
172 CC Input #9 Closed Class 1
173 CC Input #10 Closed Class 1
Table C–3: POINT LIST: OBJECTS 01 & 02 (Sheet 4 of 5)
BINARY INPUT (OBJECT 01)
BINARY INPUT CHANGE (OBJECT 02)
INDEX DESCRIPTION EVENT CLASS
ASSIGNED TO
REMARKS
