ALPS Advanced Line Protection System C-15
APPENDIX C C.3 POINT LISTS
C
87 Fault 8 Date (Middle 16-Bits)
88 Fault 8 Date (Upper 16-Bits)
89 Fault 8 Type
90 Fault 8 Trip Type
91 Fault 8 Distance
92 Fault 9 Date (Lower 16-Bits)
93 Fault 9 Date (Middle 16-Bits)
94 Fault 9 Date (Upper 16-Bits)
95 Fault 9 Type
96 Fault 9 Trip Type
97 Fault 9 Distance
98 Fault 10 Date (Lower 16-Bits)
99 Fault 10 Date (Middle 16-Bits)
100 Fault 10 Date (Upper 16-Bits)
101 Fault 10 Type
102 Fault 10 Trip Type
103 Fault 10 Distance
104 Fault 11 Date (Lower 16-Bits)
105 Fault 11 Date (Middle 16-Bits)
106 Fault 11 Date (Upper 16-Bits)
107 Fault 11 Type
108 Fault 11 Trip Type
109 Fault 11 Distance
110 Fault 12 Date (Lower 16-Bits)
111 Fault 12 Date (Middle 16-Bits)
112 Fault 12 Date (Upper 16-Bits)
113 Fault 12 Type
114 Fault 12 Trip Type
115 Fault 12 Distance
116 Fault 13 Date (Lower 16-Bits)
117 Fault 13 Date (Middle 16-Bits)
118 Fault 13 Date (Upper 16-Bits)
119 Fault 13 Type
120 Fault 13 Trip Type
121 Fault 13 Distance
122 Fault 14 Date (Lower 16-Bits)
123 Fault 14 Date (Middle 16-Bits)
124 Fault 14 Date (Upper 16-Bits)
125 Fault 14 Type
126 Fault 14 Trip Type
127 Fault 14 Distance
128 Fault 15 Date (Lower 16-Bits)
129 Fault 15 Date (Middle 16-Bits)
130 Fault 15 Date (Upper 16-Bits)
Table C–6: POINT LIST: OBJECTS 30 & 32 (Sheet 3 of 6)
ANALOG INPUT (OBJECT 30)
ANALOG INPUT CHANGE (OBJECT 32)
INDEX DESCRIPTION EVENT CLASS
ASSIGNED TO
FORMAT/
UNITS
REMARKS
1
,
2
,
3
,
4
,
5
,
6
See Table Notes followin
g
the Table
