C.3 POINT LISTS APPENDIX C
C
219 Fault 30 Date (Middle 16-Bits)
220 Fault 30 Date (Upper 16-Bits)
221 Fault 30 Type
222 Fault 30 Trip Type
223 Fault 30 Distance
224 Fault 31 Date (Lower 16-Bits)
225 Fault 31 Date (Middle 16-Bits)
226 Fault 31 Date (Upper 16-Bits)
227 Fault 31 Type
228 Fault 31 Trip Type
229 Fault 31 Distance
230 Fault 32 Date (Lower 16-Bits)
231 Fault 32 Date (Middle 16-Bits)
232 Fault 32 Date (Upper 16-Bits)
233 Fault 32 Type
234 Fault 32 Trip Type
235 Fault 32 Distance
236 Fault 33 Date (Lower 16-Bits)
237 Fault 33 Date (Middle 16-Bits)
238 Fault 33 Date (Upper 16-Bits)
239 Fault 33 Type
240 Fault 33 Trip Type
241 Fault 33 Distance
242 Fault 34 Date (Lower 16-Bits)
243 Fault 34 Date (Middle 16-Bits)
244 Fault 34 Date (Upper 16-Bits)
245 Fault 34 Type
246 Fault 34 Trip Type
247 Fault 34 Distance
248 Fault 35 Date (Lower 16-Bits)
249 Fault 35 Date (Middle 16-Bits)
250 Fault 35 Date (Upper 16-Bits)
251 Fault 35 Type
252 Fault 35 Trip Type
253 Fault 35 Distance
254 Fault 36 Date (Lower 16-Bits)
255 Fault 36 Date (Middle 16-Bits)
256 Fault 36 Date (Upper 16-Bits)
257 Fault 36 Type
258 Fault 36 Trip Type
259 Fault 36 Distance
260
Table C–6: POINT LIST: OBJECTS 30 & 32 (Sheet 6 of 6)
ANALOG INPUT (OBJECT 30)
ANALOG INPUT CHANGE (OBJECT 32)
INDEX DESCRIPTION EVENT CLASS
ASSIGNED TO
FORMAT/
UNITS
REMARKS
1
,
2
,
3
,
4
,
5
,
6
See Table Notes followin
g
the Table
