C-20 ALPS Advanced Line Protection System
GE Power Management
C.3 POINT LISTS APPENDIX C
C
25 Z3 Phase Reach
26 Z3 Phase Characteristic An
g
le
27 Z3 Ground Distance
28 Z3 Ground Reach
29 Z3 Ground Characteristic An
g
le
30 Z3 Phase Timer
31 Z3 Ground Timer
32 Z3 Ground Characteristic (ALPSQUAD)
…Reserved…(ALPS/LPS)
33 Z3 Ri
g
ht Resistive Ground Blinder (ALPSQUAD)
…Reserved…(ALPS/LPS)
34 Z4 Phase Distance
35 Z4 Phase Reach
36 Z4 Phase Characteristic An
g
le
37 …Reserved…
38 Z4 Ground Distance
39 Z4 Ground Reach
40 Z4 Ground Characteristic An
g
le
41 Z4 Direction
42 Z4 Timers
43 Z4 Phase Timer
44 Z4 Ground Timer
45 Z4 Ground Characteristic (ALPSQUAD)
…Reserved…(ALPS/LPS)
46 Z4 Ri
g
ht Resistive Ground Blinder (ALPSQUAD)
…Reserved…(ALPS/LPS)
47 Trip Supervision Current
48 Block Supervision Current
49 GDOC Trip Current
50 GDOC Block Current
51 IPB I1 Restraint
52 NT/NB Offset
53 Unbalanced Current Alarm
54 Phase Instantaneous Overcurrent
55 Directional Control 50
56 50 Pickup Settin
g
57 50 Pickup durin
g
Fuse Failure
58 Ground Instantaneous Overcurrent
59 Directional Control 50G
60 50G Pickup Settin
g
s
61 50G Pickup durin
g
Fuse Failure
62 50G Restraint Settin
g
63 Ground Time Overcurrent
64 Directional Control 51G
65 51G Pickup Settin
g
66 51G Pickup durin
g
Fuse Failure
67 51G Curve
Table C–7: POINT LIST: OBJECTS 40 & 42 (Sheet 2 of 8)
ANALOG OUTPUT (OBJECT 40)
ANALOG OUTPUT BLOCK (OBJECT 41)
INDEX DESCRIPTION FORMAT / UNITS REMARKS
