ALPS Advanced Line Protection System C-23
APPENDIX C C.3 POINT LISTS
C
160 3-Pole Second Delay
161 3-Pole Third Delay
162 3-Pole Fourth Delay
163 Reset Time
164 Contact Dwell Time
165 Inhibit Hold Select
166 Inhibit Hold Time
167 Inhibit Contact Input Sense
168 Synch. Check Supervision
169 Closin
g
An
g
le
170 Slip Frequency
171 Bus or Line Volta
g
e
172 Volta
g
e used by SYNCCHECK
173 SYNCCHECK Hold Time
174
Supervise 2
nd
3P Reclose after 1P Trip
175
Supervise 3
rd
3P Reclose after 1P Trip
176
Supervise 4
th
3P Reclose after 1P Trip
177
Supervise 1
st
3P Reclose after 3P Trip
178
Supervise 2
nd
3P Reclose after 3P Trip
179
Supervise 3
rd
3P Reclose after 3P Trip
180
Supervise 4
th
3P Reclose after 3P Trip
181 Supervise Manual Close
182 Live Bus Volta
g
e
183 Dead Bus Volta
g
e
184 Live Line Volta
g
e
185 Dead Line Volta
g
e
186 Live Bus Dead Line
187 Dead Bus Live Line
188 Dead Bus Dead Line
189 Volta
g
e Difference
190 Block Sync. Check by DELTAV
191 Non-Critical Alarm Input #1
192 Non-Critical Alarm Input #2
193 Non-Critical Alarm Input #3
194 Non-Critical Alarm Input #4
195 Non-Critical Alarm Input #5
196 Non-Critical Alarm Input #6
197 Non-Critical Alarm Input #7
198 Non-Critical Alarm Input #8
199 T1 Contact
200 T2 Contact
201 T3 Contact
202 T4 Contact
203 T5 Contact
204 T6 Contact
Table C–7: POINT LIST: OBJECTS 40 & 42 (Sheet 5 of 8)
ANALOG OUTPUT (OBJECT 40)
ANALOG OUTPUT BLOCK (OBJECT 41)
INDEX DESCRIPTION FORMAT / UNITS REMARKS
