Field replaceable units: Field replaceable units
2000966-542D Dash 3000/4000/5000 7-5
DAS assemblies - See “Replace main unit parts” on page 7-34 for disassembly.
2026653-051 DASH Generic OHMEDA DAS
 Includes Generic Ohmeda DAS assembly, labels and
hardware.
NOTE: v2B software or later required with DAS v5.
XXX
2026653-052 DASH MASIMO DAS
 Includes Masimo DAS assembly, labels and
hardware.
NOTE: v5 software or later required.
XXX
2026653-053 DASH NELLCOR-OXIMAX DAS
 Includes Nellcor OxiMax DAS assembly, labels and
hardware.
NOTE: v5.4 software or later required.
XXX
Wireless LAN assemblies
2026653-038 DASH WLAN COMPACT FLASH 802.11a/b/g
 Includes compact flash wireless card with assembled
adapter, connectors, and hardware for 802.11a/b/g.
(no antennas and no labels)
NOTE: Software version 7 or later is required.
NOTE: The compact flash wireless card with adapter
assembly is required for use with Dash CPU
processor board, PN 801424-006.
NOTE: There is no 802.11a/b/g FRU kit available to
replace failed 802.11b wireless cards. You must
order the appropriate 802.11 a/b/g wireless upgrade
and Dash software upgrade kits.
XXX
2026653-041 DASH WLAN COMPACT FLASH 802.11a/b/g
 Includes compact flash wireless card, connectors,
hardware and labels for 802.11a/b/g.
(no antennas, no labels, and no adapter)
NOTE: Software version 7 or later is required.
NOTE: There is no 802.11a/b/g FRU kit available to
replace failed 802.11b wireless cards. You must
order the appropriate 802.11 a/b/g wireless upgrade
and Dash software upgrade kits.
XXX
NBP pump assembly - See “Replace main unit parts” on page 7-34 for disassembly.
2013114-020 DASH NBP PUMP ASSEMBLY
 Includes NBP assembly and hardware.
XXX
Writer assembly or flex - See “Replace main unit parts” on page 7-34 for disassembly.
2026653-015 DASH WRITER FLEX
 Includes writer flex and hardware.
XXX
2026653-021 WRITER 50MM CS2
 Includes light gray writer with captive hardware.
XXX
Speaker assembly - See “Replace main unit parts” on page 7-34 for disassembly.
Part number Description
Dash
3000
Dash
4000
Dash
5000
