Configuration: Service menus
4-4 Dash 3000/4000/5000 2000966-542D
Boot Loader Service Menu
Activate the Boot Loader program as follows:
1. Hold down NBP Go/Stop (or NBP Auto on Dash 5000) and ZERO
ALL (FUNCTION) on the front panel.
2. Press and release the Trim Knob control.
3. Keep holding NBP Go/Stop (or NBP Auto) and ZERO ALL
(FUNCTION) until the Boot Loader information appears on the
display.
Following is a list of options in the boot code service menu.
Boot Loader Service Menu options
Menu Option Description
CHANGE INTERNET
ADDRESS
This option is used when changing the internet
protocol (IP) address.
WARNING
Duplication of an Internet address on a network
causes data loss and possible CARESCAPE Network
problems. If you change the factory assigned Internet
address, you must record all other Internet addresses
used on your network to avoid duplication.
SHOW INSTALL OPTIONS This option lists the options installed on the patient
monitor.
CLEAR CONFIGURATION
MEMORY
This option erases all patient histories and
programmed defaults in the monitor’s protected
memory. Clearing the configuration memory returns
the patient monitor defaults to the factory installed
defaults.
SET CONFIGURATION This menu contains options for configuring the patient
monitor. Refer to “Boot Code settings” on page 4-18.
VIDEO TEST SCREENS Various color screens for testing the display.
BATTERY SIMULATION This option is for engineering use only.
WAKE UP BATTERY This option is used when the battery is dead. Refer to
“How to wake up the battery” on page 5-12.
OPTIONS MENU A unique password is required for each option.
Contact your sales/service representative to obtain a
password. You must provide your product serial
number and internet address. (The internet address
is displayed in the Boot Code banner information.)
