CHAPTER 2: PRODUCT DESCRIPTION ORDER CODES
L90 LINE CURRENT DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL 2-17
2
F7 | | | | | | | | PRP, CyberSentry Lvl 1, IEC 61850, and PMU
F8 | | | | | | | | PRP, CyberSentry Lvl 1, Breaker-and-a-half, and PMU
F9 | | | | | | | | PRP, CyberSentry Lvl 1, IEC 61850, Breaker-and-a-half, and PMU
FO | | | | | | | | PRP, CyberSentry Lvl 1, In-zone transformer protection
FP | | | | | | | | PRP, CyberSentry Lvl 1, In-zone transformer protection, and IEC 61850
FQ | | | | | | | | PRP, CyberSentry Lvl 1, In-zone transformer protection, and PMU
FR | | | | | | | | PRP, CyberSentry Lvl 1, In-zone transformer protection, IEC 61850, and PMU
G0 | | | | | | | | IEEE 1588, PRP, and CyberSentry Lvl 1
G2 | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and Breaker-and-a-half
G3 | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and IEC 61850
G5 | | | | | | | | IEEE 1588, PRP, CyberSentry LVl 1, IEC 61850, and Breaker-and-a-half
G6 | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and PMU
G7 | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, IEC 61850, and PMU
G8 | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, Breaker-and-a-half, and PMU
G9 | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, IEC 16850, Breaker-and-a-half, and PMU
GO | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, In-zone transformer protection
GP | | | | | | | | IEEE 1588 PRP, CyberSentry Lvl 1, In-zone transformer protection, and IEC 61850
GQ | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, In-zone transformer protection, and PMU
GR | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, In-zone transformer protection, IEC 61850, and PMU
H0 | | | | | | | | CyberSentry Lvl 1, In-zone transformer protection, and Breaker-and-a-half
H1 | | | | | | | | CyberSentry Lvl 1, In-zone transformer protection, IEC 61850, and Breaker-and-a-half
H2 | | | | | | | | CyberSentry Lvl 1, In-zone transformer protection, Breaker-and-a-half, and PMU
H3 | | | | | | | | CyberSentry Lvl 1, In-zone transformer protection, IEC 61850, Breaker-and-a-half, and PMU
H4 | | | | | | | | IEEE 1588, In-zone transformer protection, and Breaker-and-a-half
H5 | | | | | | | | IEEE 1588, In-zone transformer protection, IEC 6850, and Breaker-and-a-half
H6 | | | | | | | | IEEE 1588, In-zone transformer protection, Breaker-and-a-half, and PMU
H7 | | | | | | | | IEEE 1588, In-zone transformer protection, IEC 61850, Breaker-and-a-half, and PMU
H8 | | | | | | | | PRP, In-zone transformer protection, and Breaker-and-a-half
H9 | | | | | | | | PRP, In-zone transformer protection, IEC 61850, and Breaker-and-a-half
HA | | | | | | | | PRP, In-zone transformer protection, Breaker-and-a-half, and PMU
HB | | | | | | | | PRP, In-zone transformer protection, IEC 61850, Breaker-and-a-half, and PMU
HC | | | | | | | | IEEE 1588, CyberSentry Lvl 1, In-zone transformer protection, and Breaker-and-a-half
HD | | | | | | | | IEEE 1588, CyberSentry Lvl 1, In-zone transformer protection, IEC 61850, and Breaker-and-a-half
HE | | | | | | | | IEEE 1588, CyberSentry Lvl 1, In-zone transformer protection, Breaker-and-a-half, and PMU
HF | | | | | | | | IEEE 1588, CyberSentry Lvl 1, In-zone transformer protection, IEC 61580, Breaker-and-a-half, PMU
HG | | | | | | | | IEEE 1588, PRP, In-zone transformer protection, and Breaker-and-a-half
HH | | | | | | | | IEEE 1588, PRP, In-zone transformer protection, IEC 61850, and Breaker-and-a-half
HI | | | | | | | | IEEE 1588, PRP, In-zone transformer protection, Breaker-and-a-half, and PMU
HJ | | | | | | | | IEEE 1588, PRP, In-zone transformer protection, IE 61850, Breaker-and-a-half, and PMU
HK | | | | | | | | PRP, CyberSentry Lvl 1, In-zone transformer protection, and Breaker-and-a-half
HL | | | | | | | | PRP, CyberSentry Lvl 1, In-zone transformer protection, IEC 61850, and Breaker-and-a-half
HM | | | | | | | | PRP, CyberSentry Lvl 1, In-zone transformer protection, Breaker-and-a-half, and PMU
HN | | | | | | | | PRP, CyberSentry Lvl 1, In-zone transformer protection, IEC 61850, Breaker-and-a-half, and PMU
HO | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, In-zone transformer protection, Breaker-and-a-half
HP | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, In-zone transformer protection, IEC 61850, Breaker-and-a-half
HQ | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, In-zone transformer protection, breaker-and-a-hal, and PMU
HR | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, In-zone Tx protection, IEC 61850, breaker-and-a half, and PMU
HS | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + In-zone transformer protection + Breaker-and-a-half
HT | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + In-zone Tx protection + IEC 61850 + Breaker-and-a-half
HU | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + In-zone transformer protection + Breaker-and-a-half + PMU
HV | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + In-zone transformer protection + IEC 61850 + Breaker-and-
a-half + PMU
HW | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + In-zone transformer protection +
Breaker-and-a-half
HX | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + In-zone transformer protection + IEC
61850 + Breaker-and-a-half
HY | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + In-zone transformer protection +
Breaker-and-a-half + PMU
HZ | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + In-zone transformer protection + IEC
61850 + PMU
J0 | | | | | | | | IEC 60870-5-103
J2 | | | | | | | | IEC 60870-5-103 + Breaker-and-a-half
J3 | | | | | | | | IEC 60870-5-103 + IEC 61850
J5 | | | | | | | | IEC 60870-5-103 + IEC 61850 + Breaker-and-a-half
J6 | | | | | | | | IEC 60870-5-103 + PMU
J7 | | | | | | | | IEC 60870-5-103 + IEC 61850 + PMU
J8 | | | | | | | | IEC 60870-5-103 + Breaker-and-a-half + PMU
J9 | | | | | | | | IEC 60870-5-103 + IEC 61850 + Breaker-and-a-half + PMU
JO | | | | | | | | IEC 60870-5-103 + In-zone transformer protection
JP | | | | | | | | IEC 60870-5-103 + In-zone transformer protection + IEC 61850
JQ | | | | | | | | IEC 60870-5-103 + In-zone transformer protection + PMU
JR | | | | | | | | IEC 60870-5-103 + In-zone transformer protection + IEC 61850 + PMU
K0 | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103
K2 | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + Breaker-and-a-half
K3 | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + IEC 61850
K5 | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + IEC 61850 + Breaker-and-a-half
K6 | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + PMU
K7 | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + IEC 61850 + PMU
K8 | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + Breaker-and-a-half + PMU
K9 | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + IEC 61850 + Breaker-and-a-half + PMU
KO | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + In-zone transformer protection
KP | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + In-zone transformer protection + IEC 61850
KQ | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + In-zone transformer protection + PMU
KR | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + In-zone transformer protection + IEC 61850 + PMU
L0 | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1
L2 | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + Breaker-and-a-half
L3 | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + IEC 61850
L5 | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + IEC 61850 + Breaker-and-a-half
L6 | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + PMU
L7 | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + IEC 61850 + PMU
L8 | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + Breaker-and-a-half + PMU
L9 | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + IEC 61850 + Breaker-and-a-half + PMU
LO | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + In-zone transformer protection
LP | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + In-zone transformer protection + IEC
61850
LQ | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + In-zone transformer protection + PMU
LR | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + In-zone transformer protection + IEC
61850 + PMU
M0 | | | | | | | | IEC 61850 + PMU + 61850-90-5
M1 | | | | | | | | IEC 61850 + Breaker and Half + PMU + 61850-90-5
M4 | | | | | | | | In-zone TX protection + IEC 61850 + PMU + 61850-90-5
M6 | | | | | | | | In-zone TX + IEC 61850 + Breaker and Half + PMU + 61850-90-5
L90 - * ** - * * * - F ** - H ** - L ** - N ** - R ** Reduced Size Vertical Mount

GE L90 Specifications

General

Communication	Ethernet, Serial
Mounting	Panel Mount
Frequency	50/60 Hz
Inputs	Digital, Analog
Outputs	Relay
Control	Local, Remote
Communication Interface	IEC 61850, DNP3, Modbus
Protection Functions	Differential, Ground Fault
Standards Compliance	IEC, IEEE
