5.8.13 Autoreclose (ANSI 79)
SETTINGS  CONTROL ELEMENTS  AUTORECLOSE  AUTORECLOSE
 AUTORECLOSE


AR FUNCTION:
Disabled
Range: Disabled, Enabled

AR MODE:
Mode 1 (1 & 3 Pole)
Range: Mode 1(1 & 3 Pole), Mode 2 (1 Pole), Mode 3 (3
Pole-A), Mode 4 (3 Pole-B)

Mode 1 Activation:
Off
Range: FlexLogic operand

Mode 2 Activation:
Off
Range: FlexLogic operand

Mode 3 Activation:
Off
Range: FlexLogic operand

Mode 4 Activation:
Off
Range: FlexLogic operand

AR MAX NUMBER OF
SHOTS: 2
Range: 1, 2, 3, 4

AR INITIATE MODE:
Protection AND CB
Range: Protection AND CB, Protection Only

AR BLOCK BKR1:
Off
Range: FlexLogic operand

AR CLOSE TIME BKR 1:
0.10 s
Range: 0.00 to 655.35 s in steps of 0.01

AR BKR MAN CLOSE:
Off
Range: FlexLogic operand

AR BLK TIME UPON MAN
CLS: 10.00 s
Range: 0.00 to 655.35 s in steps of 0.01

AR 1P INIT:
Off
Range: FlexLogic operand

AR 3P INIT:
Off
Range: FlexLogic operand

AR 3P TD INIT:
Off
Range: FlexLogic operand

AR MULTI-P FAULT:
Off
Range: FlexLogic operand

BKR ONE POLE OPEN:
Off
Range: FlexLogic operand

BKR 3 POLE OPEN:
Off
Range: FlexLogic operand

AR 3-P DEAD TIME 1:
0.50 s
Range: 0.00 to 655.35 s in steps of 0.01

AR 3-P DEAD TIME 2:
1.20 s
Range: 0.00 to 655.35 s in steps of 0.01

AR 3-P DEAD TIME 3:
2.00 s
Range: 0.00 to 655.35 s in steps of 0.01

AR 3-P DEAD TIME 4:
4.00 s
Range: 0.00 to 655.35 s in steps of 0.01

AR EXTEND DEAD T 1:
Off
Range: FlexLogic operand
