GE L90

CHAPTER 6: ACTUAL VALUES STATUS
L90 LINE CURRENT DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL 6-9
6
6.3.13 Selector switches
ACTUAL VALUES  STATUS  SELECTOR SWITCHES
The display shows both the current position and the full range. The current position only (an integer from 0 through 7) is the
actual value.
6.3.14 Flex states
ACTUAL VALUES  STATUS  FLEX STATES
There are 256 FlexState
TM
bits available. The second line value indicates the state of the given FlexState bit.
6.3.15 Ethernet
ACTUAL VALUES  STATUS  ETHERNET
These values indicate the status of the first, second, and third Ethernet links.
6.3.16 Real time clock synchronizing
ACTUAL VALUES  STATUS  REAL TIME CLOCK SYNCHRONIZING
 SELECTOR SWITCHES


SELECTOR SWITCH 1
POSITION: 0/7
Range: Current Position / 7

SELECTOR SWITCH 2
POSITION: 0/7
Range: Current Position / 7
 FLEX STATES


PARAM 1: Off
Off
Range: On, Off


PARAM 256: Off
Off
Range: On, Off
 ETHERNET


ETHERNET PRI LINK
STATUS: Fail
Range: Fail, OK

ETHERNET SEC LINK
STATUS: Fail
Range: Fail, OK

ETHERNET TER LINK
STATUS: Fail
Range: Fail, OK
 REAL TIME CLOCK
 SYNCHRONIZING

RTC SYNC SOURCE:
None
Range: see below

GRANDMASTER ID:
0X0000000000000000
Range: any 8 octet value

ACCURACY:
999999999 ns
Range: 0 to 999,999,999 ns

PORT 1 PTP STATE:
No Signal
Range: Disabled, No Signal, Calibrating, Synch’d (No
Pdelay), Synchronized

PORT 2 PTP STATE:
No Signal
Range: Disabled, No Signal, Calibrating, Synch’d (No
Pdelay), Synchronized

PORT 3 PTP STATE:
No Signal
Range: Disabled, No Signal, Calibrating, Synch’d (No
Pdelay), Synchronized

PTP - IRIG-B DELTA:
500000000 ns
Range: -500,000,000 to +500,000,000 ns
