CHAPTER 2: PRODUCT DESCRIPTION ORDER CODES
L90 LINE CURRENT DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL 2-19
2
2.4.2 Order codes with process bus modules
Table 2-6: L90 order codes for horizontal units with process bus
2F Bi-phase, dual channel
2I Channel 1 - IEEE C37.94, MM, 64/128 kbps; Channel 2 - 1300 nm, single-mode, Laser
2J Channel 1 - IEEE C37.94, MM, 64/128 kbps; Channel 2 - 1550 nm, single-mode, Laser
72 1550 nm, single-mode, Laser, 1 Channel
73 1550 nm, single-mode, Laser, 2 Channel
74 Channel 1 - RS422; Channel 2 - 1550 nm, single-mode, Laser
75 Channel 1 - G.703; Channel 2 - 1550 nm, Single-mode Laser
76 IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 1 Channel
77 IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 2 Channels
7A 820 nm, multimode, LED, 1 Channel
7B 1300 nm, multimode, LED, 1 Channel
7C 1300 nm, single-mode, ELED, 1 Channel
7D 1300 nm, single-mode, Laser, 1 Channel
7E Channel 1 - G.703; Channel 2 - 820 nm, multimode
7F Channel 1 - G.703; Channel 2 - 1300 nm, multimode
7G Channel 1 - G.703; Channel 2 - 1300 nm, single-mode ELED
7H 820 nm, multimode, LED, 2 Channels
7I 1300 nm, multimode, LED, 2 Channels
7J 1300 nm, single-mode, ELED, 2 Channels
7K 1300 nm, single-mode, Laser, 2 Channels
7L Channel 1 - RS422; Channel 2 - 820 nm, multimode, LED
7M Channel 1 - RS422; Channel 2 - 1300 nm, multimode, LED
7N Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, ELED
7P Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, Laser
7Q Channel 1 - G.703; Channel 2 - 1300 nm, single-mode Laser
7R G.703, 1 Channel
7S G.703, 2 Channels
7T RS422, 1 Channel
7V RS422, 2 Channels, 2 Clock Inputs
7W RS422, 2 Channels
L90 - * ** - * * * - F ** - H ** - L ** - N ** - S ** - W/X ** Full Size Horizontal Mount
BASE UNIT L90 | | | | | | | | | | | Base Unit
CPU T | | | | | | | | | | RS485 and Three Multi-mode fiber 100Base-FX (SFP with LC)
U | | | | | | | | | | RS485 and Two Multi-mode fiber 100Base-FX (SFP with LC), One 10/100Base-TX (SFP with
RJ45)
V | | | | | | | | | | RS485 and Three 10/100Base-TX (SFP with RJ45)
SOFTWARE OPTIONS 00 | | | | | | | | | No software options
02 | | | | | | | | | Breaker-and-a-half software
03 | | | | | | | | | IEC 61850 communications
05 | | | | | | | | | Breaker-and-a-half software and IEC 61850 communications
06 | | | | | | | | | Phasor measurement unit (PMU)
07 | | | | | | | | | IEC 61850 communications and PMU
08 | | | | | | | | | Breaker-and-a-Half and PMU
09 | | | | | | | | | Breaker-and-a-Half, IEC 61850 communications, and PMU
24 | | | | | | | | | In-zone transformer protection
25 | | | | | | | | | In-zone transformer protection and IEC 61850
26 | | | | | | | | | In-zone transformer protection and PMU
27 | | | | | | | | | In-zone transformer protection, IEC 61850, and PMU
80 | | | | | | | | | In-zone transformer and Breaker-and-a-half
81 | | | | | | | | | In-zone transformer, IEC 61850, and Breaker-and-a-half
82 | | | | | | | | | In-zone transformer, Breaker-and-a-half, and PMU
83 | | | | | | | | | In-zone transformer, IEC 61850, Breaker-and-a-half, and PMU
A0 | | | | | | | | | CyberSentry Lvl 1
A2 | | | | | | | | | CyberSentry Lvl 1 and Breaker-and-a-half
A3 | | | | | | | | | CyberSentry Lvl 1 and IEC 61850
A5 | | | | | | | | | CyberSentry Lvl 1, IEC 61850, and Breaker-and-a-half
A6 | | | | | | | | | CyberSentry Lvl 1 and PMU
A7 | | | | | | | | | CyberSentry Lvl 1, IEC 61850, and PMU
A8 | | | | | | | | | CyberSentry Lvl 1, PMU, and Breaker-and-a-half
A9 | | | | | | | | | CyberSentry Lvl 1, IEC 61850, PMU, and Breaker-and-a-half
AO | | | | | | | | | CyberSentry Lvl 1 and In-zone transformer protection
AP | | | | | | | | | CyberSentry Lvl 1, IEC 61850, and In-zone transformer protection
AQ | | | | | | | | | CyberSentry Lvl 1, PMU, and In-zone transformer protection
AR | | | | | | | | | CyberSentry Lvl 1, IEC 61850, PMU, and In-zone transformer protection
B0 | | | | | | | | | IEEE 1588
B2 | | | | | | | | | IEEE 1588 and Breaker-and-a-half
B3 | | | | | | | | | IEEE 1588 and IEC 61850
B5 | | | | | | | | | IEEE 1588 and IEC 61850 and Breaker-and-a-half
B6 | | | | | | | | | IEEE 1588 and PMU
B7 | | | | | | | | | IEEE 1588, IEC 61850, and PMU
B8 | | | | | | | | | IEEE 1588, PMU, and Breaker-and-a-half
B9 | | | | | | | | | IEEE 1588, IEC 61850, PMU, and Breaker-and-a-half
D0 | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1
BO | | | | | | | | | IEEE 1588 and In-zone transformer protection
BP | | | | | | | | | IEEE 1588, IEC 61850, and In-zone transformer protection
BQ | | | | | | | | | IEEE 1588, PMU, and In-zone transformer protection
BR | | | | | | | | | IEEE 1588, IEC 61850, PMU, and In-zone transformer protection
C0 | | | | | | | | | Parallel Redundancy Protocol (PRP)
C2 | | | | | | | | | PRP and Breaker-and-a-half
C3 | | | | | | | | | PRP and IEC 61850
C5 | | | | | | | | | PRP, IEC 61850, and Breaker-and-a-half
C6 | | | | | | | | | PRP and PMU
C7 | | | | | | | | | PRP, IEC 61850, and PMU
C8 | | | | | | | | | PRP, Breaker-and-a-half, and PMU
C9 | | | | | | | | | PRP, IEC 61850, Breaker-and-a-half, and PMU
CO | | | | | | | | | PRP and In-zone transformer protection
CP | | | | | | | | | PRP, In-zone transformer protection, and IEC 61850
CQ | | | | | | | | | PRP, In-zone transformer protection, and PMU
CR | | | | | | | | | PRP, In-zone transformer protection, IEC 61850, and PMU
D0 | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1
D2 | | | | | | | | | IEEE 1588, CyberSentry Lvl 1, and Breaker-and-a-half
D3 | | | | | | | | | IEEE 1588, CyberSentry Lvl 1, and IEC 61850
D5 | | | | | | | | | IEEE 1588, CyberSentry Lvl 1, IEC 61850, and Breaker-and-a-half
D6 | | | | | | | | | IEEE 1588, CyberSentry Lvl 1, and PMU
L90 - * ** - * * * - F ** - H ** - L ** - N ** - R ** Reduced Size Vertical Mount
