6.4.14 Restricted ground fault
ACTUAL VALUES  METERING  RESTRICTED GROUND FAULT CURRENTS  RESTRICTED GROUND FAULT 1(4)
This menu displays the differential and restraint current values for the restricted ground fault element.
6.4.15 Transducer inputs and outputs
ACTUAL VALUES  METERING  TRANSDUCER I/O DCMA INPUTS  DCMA INPUT xx
Actual values for each DCmA input channel that is enabled are displayed with the top line as the programmed channel ID
and the bottom line as the value followed by the programmed units.
ACTUAL VALUES  METERING  TRANSDUCER I/O RTD INPUTS  RTD INPUT xx
Actual values for each RTD input channel that is enabled are displayed with the top line as the programmed channel ID
and the bottom line as the value.
6.4.16 Distance
ACTUAL VALUES  METERING  DISTANCE
 RESTRICTED
 GROUND FAULT 1

RGF 1 DIFF Igd:
0.000 A

RGF 1 RESTR Igr:
0.000 A
 DCMA INPUT xx


DCMA INPUT xx
0.000 mA
 RTD INPUT xx


RTD INPUT xx
-50 °C
 DISTANCE


AB LOOP RESISTANCE
RAB: 0.00 Ohms

AB LOOP REACTANCE
XAB: 0.00 Ohms

AB LOOP IMPEDANCE
ZAB: 0.00 Ohms

AB LOOP IMPEDANCE
ANGLE: 0.00 DEG

BC LOOP RESISTANCE
RBC: 0.00 Ohms

BC LOOP REACTANCE
XBC: 0.00 Ohms

BC LOOP IMPEDANCE
ZBC: 0.00 Ohms

BC LOOP IMPEDANCE
ANGLE: 0.00 DEG

CA LOOP RESISTANCE
RCA: 0.00 Ohms

CA LOOP REACTANCE
XCA: 0.00 Ohms

CA LOOP IMPEDANCE
ZCA: 0.00 Ohms
