See the figure in the Setting Groups section of the Control Elements section later in this chapter for an example of group
activation.
5.3.12.6 Event cause LED 1(9)
SETTINGS  PRODUCT SETUP  USER-PROGRAMMABLE LEDS  EVENT CAUSE LED 1(9)
For the graphical front panel, the event cause LED settings select the FlexLogic operands that control the LEDs.
LED 1 TYPE — If set to "Self-Reset," the LED illumination tracks the state of the selected LED operand. If set to "Latched," the
LED, once lit, remains so even the LED operand state already de-asserts, until reset by the front panel RESET button, from a
remote device via a communications channel, or from any programmed operand.
The table outlines default input operand and output operands for each event cause LED.
Table 5-16: Default input and output operand for event cause LEDs
5.3.13 User-programmable self-tests
SETTINGS  PRODUCT SETUP  USER-PROGRAMMABLE SELF TESTS
 EVENT CAUSE LED 1


LED 1 OPERAND:
LED PICKUP
Range: FlexLogic operand

LED 1 COLOR:
Green
Range: Red, Green, Orange

LED 1 TYPE:
Self-Reset
Range: Self-Reset, Latched
LED Default input operand Output operand Default color
Event Cause LED 1 LED PICKUP EVENT CAUSE LED 1 Green
Event Cause LED 2 LED VOLTAGE EVENT CAUSE LED 2 Orange
Event Cause LED 3 LED CURRENT EVENT CAUSE LED 3 Orange
Event Cause LED 4 LED FREQUENCY EVENT CAUSE LED 4 Orange
Event Cause LED 5 LED OTHER EVENT CAUSE LED 5 Orange
Event Cause LED 6 LED PHASE A EVENT CAUSE LED 6 Orange
Event Cause LED 7 LED PHASE B EVENT CAUSE LED 7 Orange
Event Cause LED 8 LED PHASE C EVENT CAUSE LED 8 Orange
Event Cause LED 9 LED NEUTRAL/GROUND EVENT CAUSE LED 9 Orange
 USER-PROGRAMMABLE
 SELF TESTS

RxGOOSE OFF
FUNCTION: Enabled
Range: Disabled, Enabled

FIRST ETHERNET FAIL
FUNCTION: Disabled
Range: Disabled, Enabled

SEC. ETHERNET FAIL
FUNCTION: Disabled
Range: Disabled, Enabled

THIRD ETHERNET FAIL
FUNCTION: Disabled
Range: Disabled, Enabled

SFP MODULE FAIL
FUNCTION: Disabled
Range: Disabled, Enabled

BATTERY FAIL
FUNCTION: Enabled
Range: Disabled, Enabled

SNTP FAIL
FUNCTION: Enabled
Range: Disabled, Enabled

IRIG-B FAIL
FUNCTION: Enabled
Range: Disabled, Enabled
