local time these provide. When the RTC is synchronized with a communications protocol providing only UTC (such as PTP or
SNTP), the time offset setting is used to determine local time from the UTC provided. PTP
ALTERNATE_TIME_OFFSET_INDICATOR TLVs are not used to calculate local time.
DAYLIGHT SAVINGS TIME and DST — Can be used to allow the relay to follow the DST rules of the local time zone. Note that
when IRIG-B time synchronization is active, the local time in the IRIG-B signal contains any daylight savings time offset and
so the DST settings are ignored.
5.3.8 Fault reports
SETTINGS  PRODUCT SETUP  FAULT REPORTS  FAULT REPORT 1(4)
 FAULT REPORT 1


FAULT REPORT 1
SOURCE: SRC 1
Range: SRC 1, SRC 2, SRC 3, SRC 4

FAULT REPORT 1 TRIG:
Off
Range: FlexLogic operand

FAULT REPORT 1 Z1
MAG: 3.00 Ω
Range: 0.01 to 250.00 ohms in steps of 0.01

FAULT REPORT 1 Z1
ANGLE: 75°
Range: 25 to 90° in steps of 1

FAULT REPORT 1 Z0
MAG: 9.00 Ω
Range: 0.01 to 650.00 ohms in steps of 0.01

FAULT REPORT 1 Z0
ANGLE: 75°
Range: 25 to 90° in steps of 1

FAULT REPORT 1 Z0M
MAG: 0.00 Ω
Range: 0.00 to 650.00 ohms in steps of 0.01

FAULT REPORT 1 Z0M
ANGLE: 0°
Range: 25 to 90° in steps of 1

FAULT REPORT 1 LINE
LENGTH UNITS: km
Range: km, miles

FAULT REP 1 LENGTH
(km ): 100.0
Range: 0.0 to 2000.0 in steps of 0.1

FAULT REP 1 REM1-TAP
Z1 MAG: 3.00 Ω
Range: 0.01 to 250.00 ohms in steps of 0.01

FAULT REP 1 REM1-TAP
Z1 ANG: 75°
Range: 25 to 90° in steps of 1

FAULT REP 1 REM1-TAP
LENGTH (km ): 100.0
Range: 0.0 to 2000.0 in steps of 0.1

FAULT REP 1 REM2-TAP
Z1 MAG: 3.00 Ω
Range: 0.01 to 250.00 ohms in steps of 0.01

FAULT REP 1 REM2-TAP
Z1 ANG: 75°
Range: 25 to 90° in steps of 1

FAULT REP 1 REM2-TAP
LENGTH (km ): 100.0
Range: 0.0 to 2000.0 in steps of 0.1

FAULT REPORT 1 VT
SUBSTITUTION: None
Range: None, I0, V0

FAULT REP 1 SYSTEM
Z0 MAG: 2.00 Ω
Range: 0.01 to 650.00 ohms in steps of 0.01

FAULT REP 1 SYSTEM
Z0 ANGLE: 75°
Range: 25 to 90° in steps of 1
