GE L90

CHAPTER 6: ACTUAL VALUES METERING
L90 LINE CURRENT DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL 6-17
6
6.4.3 Sources
6.4.3.1 Menu
ACTUAL VALUES  METERING  SOURCE SRC 1
This menu displays the metered values available for each source.
Metered values presented for each source depend on the phase and auxiliary VTs and phase and ground CTs assignments
for this particular source. For example, if no phase VT is assigned to this source, then any voltage, energy, and power
values are unavailable.
6.4.3.2 Phase current metering
ACTUAL VALUES  METERING  SOURCE SRC 1  PHASE CURRENT
 SOURCE SRC 1


 PHASE CURRENT
 SRC 1
See below

 GROUND CURRENT
 SRC 1
See page 6-18

 PHASE VOLTAGE
 SRC 1
See page 6-18

 AUXILIARY VOLTAGE
 SRC 1
See page 6-19

 POWER
 SRC 1
See page 6-19

 ENERGY
 SRC 1
See page 6-20

 DEMAND
 SRC 1
See page 6-20

 FREQUENCY
 SRC 1
See page 6-21

 CURRENT HARMONICS
 SRC 1
See page 6-22

 VOLTAGE HARMONICS
 SRC 1
See page 6-22
 PHASE CURRENT
 SRC 1

SRC 1 RMS Ia: 0.000
b: 0.000 c: 0.000 A

SRC 1 RMS Ia:
0.000 A

SRC 1 RMS Ib:
0.000 A

SRC 1 RMS Ic:
0.000 A

SRC 1 RMS In:
0.000 A

SRC 1 PHASOR Ia:
0.000 A 0.0°

SRC 1 PHASOR Ib:
0.000 A 0.0°

SRC 1 PHASOR Ic:
0.000 A 0.0°
