CHAPTER 6: ACTUAL VALUES RECORDS
L90 LINE CURRENT DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL 6-33
6
6.5.5 Phasor Measurement Unit records
ACTUAL VALUES  RECORDS  PMU RECORDS
The number of triggers applicable to the Phasor Measurement Unit recorder is indicated by the
NUMBER OF TRIGGERS value.
The status of the phasor measurement unit recorder is indicated as follows.
ACTUAL VALUES  RECORDS  PMU RECORDS  PMU 1 RECORDING
6.5.6 Breaker maintenance
ACTUAL VALUES  RECORDS  MAINTENANCE  BREAKER 1(4)
 PMU
 RECORDS

NUMBER OF TRIGGERS:
0
Range: 0 to 65535 in steps of 1

 PMU 1
 RECORDING
See below
 PMU 1
 RECORDINg

PMU 1 FORCE TRIGGER:
Yes
Range: No, Yes

PUM 1 AVAILABLE
RECORDS: 0
Range: 0 to 65535 in steps of 1

PUM 1 SECONDS
PER RECORD: 0.0
Range: 0 to 6553.5 in steps of 0.1

PUM 1 LAST CLEARED:
2013/07/14 15:40:16
Range: YYYY/MM/DD HH:MM:SS
 BREAKER 1


BKR 1 ACC ARCING AMP
φA: 0.00 kA2-cyc

BKR 1 ACC ARCING AMP
φB: 0.00 kA2-cyc

BKR 1 ACC ARCING AMP
φC: 0.00 kA2-cyc

BKR 1 OPERATING TIME
φA: 0 ms

BKR 1 OPERATING TIME
φB: 0 ms

BKR 1 OPERATING TIME
φC: 0 ms

BKR 1 OPERATING
TIME: 0 ms

BKR 1 ARCING AMP φA:
0.00 kA2-cyc

BKR 1 ARCING AMP φB:
0.00 kA2-cyc

BKR 1 ARCING AMP φC:
0.00 kA2-cyc

BKR 1 AMP MAX φA:
0.00 kA

BKR 1 AMP MAX φB:
0.00 kA

BKR 1 AMP MAX φC:
0.00 kA
