CHAPTER 6: ACTUAL VALUES METERING

L90 LINE CURRENT DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL 6-19

The metered phase voltage values are displayed in this menu. The "SRC 1" text is replaced by the name programmed by

the user for the associated source (see

SETTINGS  SYSTEM SETUP  SIGNAL SOURCES).

6.4.3.5 Auxiliary voltage metering

ACTUAL VALUES  METERING  SOURCE SRC 1  AUXILIARY VOLTAGE

The metered auxiliary voltage values are displayed in this menu. The "SRC 1" text is replaced by the name programmed by

the user for the associated source (see

SETTINGS  SYSTEM SETUP  SIGNAL SOURCES).

6.4.3.6 Power metering

ACTUAL VALUES  METERING  SOURCE SRC 1  POWER



SRC 1 PHASOR Vca:

0.000 V 0.0°



SRC 1 ZERO SEQ V0:

0.000 V 0.0°



SRC 1 POS SEQ V1:

0.000 V 0.0°



SRC 1 NEG SEQ V2:

0.000 V 0.0°

 AUXILIARY VOLTAGE

 SRC 1



SRC 1 RMS Vx:

0.00 V



SRC 1 PHASOR Vx:

0.000 V 0.0°

 POWER

 SRC 1



SRC 1 REAL POWER

3φ: 0.000 W



SRC 1 REAL POWER

φa: 0.000 W



SRC 1 REAL POWER

φb: 0.000 W



SRC 1 REAL POWER

φc: 0.000 W



SRC 1 REACTIVE PWR

3φ: 0.000 var



SRC 1 REACTIVE PWR

φa: 0.000 var



SRC 1 REACTIVE PWR

φb: 0.000 var



SRC 1 REACTIVE PWR

φc: 0.000 var



SRC 1 APPARENT PWR

3φ: 0.000 VA



SRC 1 APPARENT PWR

φa: 0.000 VA



SRC 1 APPARENT PWR

φb: 0.000 VA



SRC 1 APPARENT PWR

φc: 0.000 VA
