The configuration menu allows a maximum of four ASDUs containing measurands.
Measurands are sent as a response to Class 2 requests, which are cyclic requests coming from the master.
TYPE IDENTIFICATION (TYP) — The configuration field TYP indicates how many measurands are present in the corresponding
ASDU. Each ASDU can take either 4 or 9 measurands maximum, depending on the type identification (3 respectively 9). For
any change to take effect, restart the relay.
FUNCTION TYPE (FUN) and INFORMATION NUMBER (INF) — These two fields form the Information Object Identifier of the ASDU
as defined in IEC 60870-103. For any change to take effect, restart the relay.
SCAN TIMEOUT (SCAN TOUT) — This is the cyclic period used by the L90 to decide when a measurand ASDU is included in a
response. The measurand is sent as response to a Class 2 request when the corresponding timeout expires. The default
value 0 means 500 ms.

ASDU 1 ANALOG 1
Off
Range: FlexAnalog parameter

ASDU 1 ANALOG 1
FACTOR: 1.000
Range: 0.000 to 65.535 in steps of 0.001

ASDU 1 ANALOG 1
OFFSET: 0
Range: -32768 to 32767 in steps of 1


ASDU 1 ANALOG 9
Off
Range: FlexAnalog parameter

ASDU 1 ANALOG 9
FACTOR: 1.000
Range: 0.000 to 65.535 in steps of 0.001

ASDU 1 ANALOG 9
OFFSET: 0
Range: -32768 to 32767 in steps of 1

 ASDU 4


ASDU 4 TYP:
9
Range: 3 or 9

ASDU 4 FUN:
0
Range: 0 to 255 in steps of 1

ASDU 4 INF:
0
Range: 0 to 255 in steps of 1

ASDU 4 SCAN TOUT:
0
Range: 0 to 1000 s in steps of 1

ASDU 4 ANALOG 1
Off
Range: FlexAnalog parameter

ASDU 4 ANALOG 1
FACTOR: 1.000
Range: 0.000 to 65.535 in steps of 0.001

ASDU 4 ANALOG 1
OFFSET: 0
Range: -32768 to 32767 in steps of 1


ASDU 4 ANALOG 9
Off
Range: FlexAnalog parameter

ASDU 4 ANALOG 9
FACTOR: 1.000
Range: 0.000 to 65.535 in steps of 0.001

ASDU 4 ANALOG 9
OFFSET: 0
Range: -32768 to 32767 in steps of 1
