CHAPTER 2: PRODUCT DESCRIPTION ORDER CODES
L90 LINE CURRENT DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL 2-21
2
J9 | | | | | | | | | IEC 60870-5-103 + IEC 61850 + Breaker-and-a-half + PMU
JO | | | | | | | | | IEC 60870-5-103 + In-zone transformer protection
JP | | | | | | | | | IEC 60870-5-103 + In-zone transformer protection + IEC 61850
JQ | | | | | | | | | IEC 60870-5-103 + In-zone transformer protection + PMU
JR | | | | | | | | | IEC 60870-5-103 + In-zone transformer protection + IEC 61850 + PMU
K0 | | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103
K2 | | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + Breaker-and-a-half
K3 | | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + IEC 61850
K5 | | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + IEC 61850 + Breaker-and-a-half
K6 | | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + PMU
K7 | | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + IEC 61850 + PMU
K8 | | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + Breaker-and-a-half + PMU
K9 | | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + IEC 61850 + Breaker-and-a-half + PMU
KO | | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + In-zone transformer protection
KP | | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + In-zone transformer protection + IEC 61850
KQ | | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + In-zone transformer protection + PMU
KR | | | | | | | | | IEEE 1588 + PRP + IEC60870-5-103 + In-zone transformer protection + IEC 61850 + PMU
L0 | | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1
L2 | | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + Breaker-and-a-half
L3 | | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + IEC 61850
L5 | | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + IEC 61850 + Breaker-and-a-half
L6 | | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + PMU
L7 | | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + IEC 61850 + PMU
L8 | | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + Breaker-and-a-half + PMU
L9 | | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + IEC 61850 + Breaker-and-a-half +
PMU
LO | | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + In-zone transformer protection
LP | | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + In-zone transformer protection +
IEC 61850
LQ | | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + In-zone transformer protection +
PMU
LR | | | | | | | | | IEC60870-5-103 + IEEE 1588 + PRP + CyberSentry Lvl 1 + In-zone transformer protection +
IEC 61850 + PMU
M0 | | | | | | | | | IEC 61850 + PMU + 61850-90-5
M1 | | | | | | | | | IEC 61850 + Breaker and Half + PMU + 61850-90-5
M4 | | | | | | | | | In-zone TX protection + IEC 61850 + PMU + 61850-90-5
M6 | | | | | | | | | In-zone TX + IEC 61850 + Breaker and Half + PMU + 61850-90-5
M7 | | | | | | | | | CyberSentry UR Lvl 1 + IEC 61850 + PMU + 61850-90-5
M8 | | | | | | | | | CyberSentry UR Lvl 1 + IEC 61850 + Breaker and Half + PMU + 61850-90-5
MB | | | | | | | | | CyberSentry UR Lvl 1 + In-zone TX protection + IEC 61850 + PMU + 61850-90-5
MD | | | | | | | | | IEEE 1588 + IEC 61850 + PMU + 61850-90-5
ME | | | | | | | | | IEEE 1588 + IEC 61850 + Breaker and Half + PMU + 61850-90-5
MH | | | | | | | | | IEEE 1588 + In-zone TX protection + IEC 61850 + PMU + 61850-90-5
MJ | | | | | | | | | PRP + IEC 61850 + PMU + 61850-90-5
MK | | | | | | | | | PRP + IEC 61850 + Breaker and Half + PMU + 61850-90-5
MN | | | | | | | | | PRP + In-zone TX protection + IEC 61850 + PMU + 61850-90-5
MP | | | | | | | | | IEEE 1588 + CyberSentry UR Lvl 1 + IEC 61850 + PMU + 61850-90-5
MQ | | | | | | | | | IEEE 1588 + CyberSentry UR Lvl 1 + IEC 61850 + Breaker and Half + PMU + 61850-90-5
MT | | | | | | | | | IEEE 1588 + CyberSentry UR Lvl 1 + In-zone TX protection + IEC 61850 + PMU + 61850-90-5
MV | | | | | | | | | IEEE 1588 + PRP + IEC 61850 + PMU + 61850-90-5
MW | | | | | | | | | IEEE 1588 + PRP + IEC 61850 + Breaker and Half + PMU + 61850-90-5
MZ | | | | | | | | | IEEE 1588 + PRP + In-zone TX protection + IEC 61850 + PMU + 61850-90-5
N1 | | | | | | | | | PRP + CyberSentry UR Lvl 1 + IEC 61850 + PMU + 61850-90-5
N2 | | | | | | | | | PRP + CyberSentry UR Lvl 1 + IEC 61850 + Breaker and Half + PMU + 61850-90-5
N5 | | | | | | | | | PRP + CyberSentry UR Lvl 1 + In-zone TX protection + IEC 61850 + PMU + 61850-90-5
N7 | | | | | | | | | IEEE 1588 + PRP + CyberSentry UR Lvl 1 + IEC 61850 + PMU + 61850-90-5
N8 | | | | | | | | | IEEE 1588 + PRP + CyberSentry UR Lvl 1 + IEC 61850 + Breaker and Half + PMU + 61850-90-
5
NB | | | | | | | | | IEEE 1588 + PRP + CyberSentry UR Lvl 1 + In-zone TX protection + IEC 61850 + PMU +
61850-90-5
ND | | | | | | | | | IEC 60870-5-103 + IEC 61850 + PMU + 61850-90-5
NE | | | | | | | | | IEC 60870-5-103 + IEC 61850 + Breaker and Half + PMU + 61850-90-5
NH | | | | | | | | | IEC 60870-5-103 + In-zone TX protection + IEC 61850 + PMU + 61850-90-5
NJ | | | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + IEC 61850 + PMU + 61850-90-5
NK | | | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + IEC 61850 + Breaker and Half + PMU + 61850-90-5
NN | | | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + In-zone TX protection + IEC 61850 + PMU + 61850-
90-5
NP | | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry UR Lvl 1 + IEC 61850 + PMU + 61850-90-
5
NQ | | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry UR Lvl 1 + IEC 61850 + Breaker and Half
+ PMU + 61850-90-5
NT | | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry UR Lvl 1 + In-zone TX protection + IEC
61850 + PMU + 61850-90-5
NV | | | | | | | | | CyberSentry UR Lvl 1 + In-zone TX + IEC 61850 + Breaker and Half + PMU + 61850-90-5
NW | | | | | | | | | IEEE 1588 + In-zone TX + IEC 61850 + Breaker and Half + PMU + 61850-90-5
NX | | | | | | | | | PRP + In-zone TX + IEC 61850 + Breaker and Half + PMU + 61850-90-5
NY | | | | | | | | | IEEE 1588 + CyberSentry UR Lvl 1 + In-zone TX + IEC 61850 + Breaker and Half + PMU +
61850-90-5
NZ | | | | | | | | | IEEE 1588 + PRP + In-zone TX + IEC 61850 + Breaker and Half + PMU + 61850-90-5
O0 | | | | | | | | | PRP + CyberSentry UR Lvl 1 + In-zone TX + IEC 61850 + Breaker and Half + PMU + 61850-
90-5
O1 | | | | | | | | | IEEE 1588 + PRP + CyberSentry UR Lvl 1 + In-zone TX + IEC 61850 + Breaker and Half + PMU
+ 61850-90-5
O2 | | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + In-zone TX + IEC 61850 + Breaker and Half + PMU +
61850-90-5
O3 | | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry UR Lvl 1 + In-zone TX + IEC 61850 +
Breaker and Half + PMU + 61850-90-5
L90 - * ** - * * * - F ** - H ** - L ** - N ** - S ** - W/X ** Full Size Horizontal Mount
BASE UNIT L90 | | | | | | | | | | | Base Unit
