GE L90

CHAPTER 2: PRODUCT DESCRIPTION ORDER CODES
L90 LINE CURRENT DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL 2-23
2
Table 2-7: L90 order codes for reduced-size vertical units with process bus
L90 - * ** - * * * - F ** - H ** - L ** - N ** - R ** Reduced Size Vertical Mount
BASE UNIT L90 | | | | | | | | | | Base Unit
CPU T | | | | | | | | | RS485 and Three Multi-mode fiber 100Base-FX (SFP with LC)
U | | | | | | | | | RS485 and Two Multi-mode fiber 100Base-FX (SFP with LC), One 10/100Base-TX (SFP with RJ45)
V | | | | | | | | | RS485 and Three 10/100Base-TX (SFP with RJ45)
SOFTWARE OPTIONS 00 | | | | | | | | No software options
02 | | | | | | | | Breaker-and-a-half software
03 | | | | | | | | IEC 61850 communications
05 | | | | | | | | Breaker-and-a-half software and IEC 61850 communications
06 | | | | | | | | Phasor measurement unit (PMU)
07 | | | | | | | | IEC 61850 communications and PMU
08 | | | | | | | | Breaker-and-a-Half and PMU
09 | | | | | | | | Breaker-and-a-Half, IEC 61850 communications, and PMU
24 | | | | | | | | In-zone transformer protection
25 | | | | | | | | In-zone transformer protection and IEC 61850
26 | | | | | | | | In-zone transformer protection and PMU
27 | | | | | | | | In-zone transformer protection, IEC 61850, and PMU
80 | | | | | | | | In-zone transformer and Breaker-and-a-half
81 | | | | | | | | In-zone transformer, IEC 61850, and Breaker-and-a-half
82 | | | | | | | | In-zone transformer, Breaker-and-a-half, and PMU
83 | | | | | | | | In-zone transformer, IEC 61850, Breaker-and-a-half, and PMU
A0 | | | | | | | | CyberSentry Lvl 1
A2 | | | | | | | | CyberSentry Lvl 1 and Breaker-and-a-half
A3 | | | | | | | | CyberSentry Lvl 1 and IEC 61850
A5 | | | | | | | | CyberSentry Lvl 1, IEC 61850, and Breaker-and-a-half
A6 | | | | | | | | CyberSentry Lvl 1 and PMU
A7 | | | | | | | | CyberSentry Lvl 1, IEC 61850, and PMU
A8 | | | | | | | | CyberSentry Lvl 1, PMU, and Breaker-and-a-half
A9 | | | | | | | | CyberSentry Lvl 1, IEC 61850, PMU, and Breaker-and-a-half
AO | | | | | | | | CyberSentry Lvl 1 and In-zone transformer protection
AP | | | | | | | | CyberSentry Lvl 1, IEC 61850, and In-zone transformer protection
AQ | | | | | | | | CyberSentry Lvl 1, PMU, and In-zone transformer protection
AR | | | | | | | | CyberSentry Lvl 1, IEC 61850, PMU, and In-zone transformer protection
B0 | | | | | | | | IEEE 1588
B2 | | | | | | | | IEEE 1588 and Breaker-and-a-half
B3 | | | | | | | | IEEE 1588 and IEC 61850
B5 | | | | | | | | IEEE 1588, IEC 61850, and Breaker-and-a-half
B6 | | | | | | | | IEEE 1588 and PMU
B7 | | | | | | | | IEEE 1588, IEC 61850, and PMU
B8 | | | | | | | | IEEE 1588, PMU, and Breaker-and-a-half
B9 | | | | | | | | IEEE 1588, IEC 61850, PMU, and Breaker-and-a-half
BO | | | | | | | | IEEE 1588 and In-zone transformer protection
BP | | | | | | | | IEEE 1588, IEC 61850, and In-zone transformer protection
BQ | | | | | | | | IEEE 1588, PMU, and In-zone transformer protection
BR | | | | | | | | IEEE 1588, IEC 61850, PMU, and In-zone transformer protection
C0 | | | | | | | | Parallel Redundancy Protocol (PRP)
C2 | | | | | | | | PRP and Breaker-and-a-half
C3 | | | | | | | | PRP and IEC 61850
C5 | | | | | | | | PRP, IEC 61850, and Breaker-and-a-half
C6 | | | | | | | | PRP and PMU
C7 | | | | | | | | PRP, IEC 61850, and PMU
C8 | | | | | | | | PRP, Breaker-and-a-half, and PMU
C9 | | | | | | | | PRP, IEC 61850, Breaker-and-a-half, and PMU
CO | | | | | | | | PRP and In-zone transformer protection
CP | | | | | | | | PRP, In-zone transformer protection, and IEC 61850
CQ | | | | | | | | PRP, In-zone transformer protection, and PMU
CR | | | | | | | | PRP, In-zone transformer protection, IEC 61850, and PMU
D0 | | | | | | | | IEEE 1588 and CyberSentry Lvl 1
D2 | | | | | | | | IEEE 1588, CyberSentry Lvl 1, and IEC 61850
D3 | | | | | | | | IEEE 1588, CyberSentry Lvl 1, and IEC 61850
D5 | | | | | | | | IEEE 1588, CyberSentry Lvl 1, and IEC 61850
D6 | | | | | | | | IEEE 1588, CyberSentry Lvl 1, and PMU
D7 | | | | | | | | IEEE 1588, CyberSentry Lvl 1, IEC 61850, and PMU
D8 | | | | | | | | IEEE 1588, CyberSentry Lvl 1, IEC 61850, and PMU
D9 | | | | | | | | IEEE 1588, CyberSentry Lvl 1, IEC 61850, PMU, and Breaker-and-a-half
DO | | | | | | | | IEEE 1588, CyberSentry Lvl 1, and In-zone transformer protection
DP | | | | | | | | IEEE 1588, CyberSentry Lvl 1, IEC 61850, and In-zone transformer protection
DQ | | | | | | | | IEEE 1588, CyberSentry Lvl 1, PMU, and In-zone transformer protection
DR | | | | | | | | IEEE 1588, CyberSentry Lvl 1, IEC 61850, PMU, and In-zone transformer protection
E0 | | | | | | | | IEEE 1588 and PRP
E2 | | | | | | | | IEEE 1588, PRP, and Breaker-and-a-half
E3 | | | | | | | | IEEE 1588, PRP, and IEC 61850
E5 | | | | | | | | IEEE 1588, PRP, IEC 61850, and Breaker-and-a-half
E6 | | | | | | | | IEEE 1588, PRP, and PMU
E7 | | | | | | | | IEEE 1588, PRP, IEC 61850, and PMU
E8 | | | | | | | | IEEE 1588, PRP, Breaker-and-a-half, and PMU
E9 | | | | | | | | IEEE 1588, PRP, IEC 61850, Breaker-and-a-half, and PMU
EO | | | | | | | | IEEE 1588, PRP, and In-zone transformer protection
EP | | | | | | | | IEEE 1588, PRP, In-zone transformer protection, and IEC 61850
EQ | | | | | | | | IEEE 1588, PRP, In-zone transformer protection, and PMU
ER | | | | | | | | IEEE 1588, PRP, In-zone transformer protection, IEC 61850, and PMU
F0 | | | | | | | | PRP and CyberSentry Lvl 1
F2 | | | | | | | | PRP, CyberSentry Lvl 1, and Breaker-and-a-half
F3 | | | | | | | | PRP, CyberSentry Lvl 1, and IEC 61850
F5 | | | | | | | | PRP, CyberSentry Lvl 1, IEC 61850, and Breaker-and-a-half
F6 | | | | | | | | PRP, CyberSentry Lvl 1, and PMU
F7 | | | | | | | | PRP, CyberSentry Lvl 1, IEC 61850, and PMU
F8 | | | | | | | | PRP, CyberSentry Lvl 1, Breaker-and-a-half, and PMU
F9 | | | | | | | | PRP, CyberSentry Lvl 1, IEC 61850, Breaker-and-a-half, and PMU
FO | | | | | | | | PRP, CyberSentry Lvl 1,In-zone transformer protection
FP | | | | | | | | PRP, CyberSentry Lvl 1,In-zone transformer protection, and IEC 61850
FQ | | | | | | | | PRP, CyberSentry Lvl 1, In-zone transformer protection, and PMU
FR | | | | | | | | PRP, CyberSentry Lvl 1, In-zone transformer protection, IEC 61850, and PMU
G0 | | | | | | | | IEEE 1588, PRP, and CyberSentry Lvl 1
G2 | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and Breaker-and-a-half
G3 | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and IEC 61850
G5 | | | | | | | | IEEE 1588, PRP, CyberSentry LVl 1, IEC 61850, and Breaker-and-a-half
G6 | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and PMU
G7 | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, IEC 61850, and PMU
G8 | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, Breaker-and-a-half, and PMU
G9 | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, IEC 16850, Breaker-and-a-half, and PMU
GO | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, In-zone transformer protection
