CHAPTER 2: PRODUCT DESCRIPTION ORDER CODES
L90 LINE CURRENT DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL 2-25
2
N2 | | | | | | | | PRP + CyberSentry UR Lvl 1 + IEC 61850 + Breaker and Half + PMU + 61850-90-5
N5 | | | | | | | | PRP + CyberSentry UR Lvl 1 + In-zone TX protection + IEC 61850 + PMU + 61850-90-5
N7 | | | | | | | | IEEE 1588 + PRP + CyberSentry UR Lvl 1 + IEC 61850 + PMU + 61850-90-5
N8 | | | | | | | | IEEE 1588 + PRP + CyberSentry UR Lvl 1 + IEC 61850 + Breaker and Half + PMU + 61850-90-5
NB | | | | | | | | IEEE 1588 + PRP + CyberSentry UR Lvl 1 + In-zone TX protection + IEC 61850 + PMU + 61850-90-5
ND | | | | | | | | IEC 60870-5-103 + IEC 61850 + PMU + 61850-90-5
NE | | | | | | | | IEC 60870-5-103 + IEC 61850 + Breaker and Half + PMU + 61850-90-5
NH | | | | | | | | IEC 60870-5-103 + In-zone TX protection + IEC 61850 + PMU + 61850-90-5
NJ | | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + IEC 61850 + PMU + 61850-90-5
NK | | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + IEC 61850 + Breaker and Half + PMU + 61850-90-5
NN | | | | | | | | IEEE 1588 + PRP + IEC 60870-5-103 + In-zone TX protection + IEC 61850 + PMU + 61850-90-5
NP | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry UR Lvl 1 + IEC 61850 + PMU + 61850-90-5
NQ | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry UR Lvl 1 + IEC 61850 + Breaker and Half + PMU
+ 61850-90-5
NT | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry UR Lvl 1 + In-zone TX protection + IEC 61850 +
PMU + 61850-90-5
NV | | | | | | | | CyberSentry UR Lvl 1 + In-zone TX + IEC 61850 + Breaker and Half + PMU + 61850-90-5
NW | | | | | | | | IEEE 1588 + In-zone TX + IEC 61850 + Breaker and Half + PMU + 61850-90-5
NX | | | | | | | | PRP + In-zone TX + IEC 61850 + Breaker and Half + PMU + 61850-90-5
NY | | | | | | | | IEEE 1588 + CyberSentry UR Lvl 1 + In-zone TX + IEC 61850 + Breaker and Half + PMU + 61850-90-
5
NZ | | | | | | | | IEEE 1588 + PRP + In-zone TX + IEC 61850 + Breaker and Half + PMU + 61850-90-5
O0 | | | | | | | | PRP + CyberSentry UR Lvl 1 + In-zone TX + IEC 61850 + Breaker and Half + PMU + 61850-90-5
O1 | | | | | | | | IEEE 1588 + PRP + CyberSentry UR Lvl 1 + In-zone TX + IEC 61850 + Breaker and Half + PMU +
61850-90-5
O2 | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + In-zone TX + IEC 61850 + Breaker and Half + PMU + 61850-
90-5
O3 | | | | | | | | IEC 60870-5-103 + IEEE 1588 + PRP + CyberSentry UR Lvl 1 + In-zone TX + IEC 61850 + Breaker
and Half + PMU + 61850-90-5
MOUNT/COATING V | | | | | | | Vertical (3/4 rack)
B | | | | | | | Vertical (3/4 rack) with harsh environmental coating
FRONT PANEL + INTERFACE F | | | | | | English display
D | | | | | | French display
R | | | | | | Russian display
A | | | | | | Chinese display
K | | | | | | Enhanced front panel with English display
M | | | | | | Enhanced front panel with French display
Q | | | | | | Enhanced front panel with Russian display
U | | | | | | Enhanced front panel with Chinese display
L | | | | | | Enhanced front panel with English display and user-programmable pushbuttons
N | | | | | | Enhanced front panel with French display and user-programmable pushbuttons
T | | | | | | Enhanced front panel with Russian display and user-programmable pushbuttons
V | | | | | | Enhanced front panel with Chinese display and user-programmable pushbuttons
W | | | | | | Enhanced front panel with Turkish display
Y | | | | | | Enhanced front panel with Turkish display and user-programmable pushbuttons
I | | | | | | Enhanced front panel with German display
J | | | | | | Enhanced front panel with German display and user-programmable pushbuttons
POWER SUPPLY H | | | | | 125 / 250 V AC/DC power supply
L | | | | | 24 to 48 V (DC only) power supply
PROCESS BUS MODULE | 81 | | | Eight-port digital process bus module
CONTACT INPUTS/OUTPUTS XX XX XX XX No Module
4A | 4 Solid-State (no monitoring) MOSFET outputs
4B | 4 Solid-State (voltage with optional current) MOSFET outputs
4C | 4 Solid-State (current with optional voltage) MOSFET outputs
4D | 16 Contact inputs with Auto-Burnishing (maximum of three modules within a case)
4L | 14 Form-A (no monitoring) Latching outputs
67 | 8 Form-A (no monitoring) outputs
6A | 2 Form-A (voltage with optional current) and 2 Form-C outputs, 8 contact inputs
6B | 2 Form-A (voltage with optional current) and 4 Form-C outputs, 4 contact inputs
6C | 8 Form-C outputs
6D | 16 Contact inputs
6E | 4 Form-C outputs, 8 contact inputs
6F | 8 Fast Form-C outputs
6G | 4 Form-A (voltage with optional current) outputs, 8 contact inputs
6H | 6 Form-A (voltage with optional current) outputs, 4 contact inputs
6K | 4 Form-C and 4 Fast Form-C outputs
6L | 2 Form-A (current with optional voltage) and 2 Form-C outputs, 8 contact inputs
6M | 2 Form-A (current with optional voltage) and 4 Form-C outputs, 4 contact inputs
6N | 4 Form-A (current with optional voltage) outputs, 8 contact inputs
6P | 6 Form-A (current with optional voltage) outputs, 4 contact inputs
6R | 2 Form-A (no monitoring) and 2 Form-C outputs, 8 contact inputs
6S | 2 Form-A (no monitoring) and 4 Form-C outputs, 4 contact inputs
6T | 4 Form-A (no monitoring) outputs, 8 contact inputs
6U | 6 Form-A (no monitoring) outputs, 4 contact inputs
6V | 2 Form-A outputs, 1 Form-C output, 2 Form-A (no monitoring) latching outputs, 8 contact inputs
INTER-RELAY
COMMUNICATIONS
(select a maximum of 1 per unit)
2A C37.94SM, 1300 nm single-mode, ELED, 1 channel single-mode
2B C37.94SM, 1300 nm single-mode, ELED, 2 channel single-mode
2E Bi-phase, single channel
2F Bi-phase, dual channel
2I Channel 1 - IEEE C37.94, MM, 64/128 kbps; Channel 2 - 1300 nm, single-mode, Laser
2J Channel 1 - IEEE C37.94, MM, 64/128 kbps; Channel 2 - 1550 nm, single-mode, Laser
72 1550 nm, single-mode, Laser, 1 Channel
73 1550 nm, single-mode, Laser, 2 Channel
74 Channel 1 - RS422; Channel 2 - 1550 nm, single-mode, Laser
75 Channel 1 - G.703; Channel 2 - 1550 nm, Single-mode Laser
76 IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 1 Channel
77 IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 2 Channels
7A 820 nm, multimode, LED, 1 Channel
7B 1300 nm, multimode, LED, 1 Channel
7C 1300 nm, single-mode, ELED, 1 Channel
7D 1300 nm, single-mode, Laser, 1 Channel
7E Channel 1 - G.703; Channel 2 - 820 nm, multimode
7F Channel 1 - G.703; Channel 2 - 1300 nm, multimode
7G Channel 1 - G.703; Channel 2 - 1300 nm, single-mode ELED
7H 820 nm, multimode, LED, 2 Channels
7I 1300 nm, multimode, LED, 2 Channels
7J 1300 nm, single-mode, ELED, 2 Channels
7K 1300 nm, single-mode, Laser, 2 Channels
7L Channel 1 - RS422; Channel 2 - 820 nm, multimode, LED
7M Channel 1 - RS422; Channel 2 - 1300 nm, multimode, LED
7N Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, ELED
7P Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, Laser
L90 - * ** - * * * - F ** - H ** - L ** - N ** - R ** Reduced Size Vertical Mount
