GE L90

CHAPTER 3: INSTALLATION WIRING
L90 LINE CURRENT DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL 3-19
3
~6P module ~6R module ~6S module ~6T module
Terminal
assignment
Output or
input
Terminal
assignment
Output or
input
Terminal
assignment
Output or
input
Terminal
assignment
Output or
input
~1 Form-A ~1Form-A~1Form-A~1Form-A
~2 Form-A ~2Form-A~2Form-A~2Form-A
~3 Form-A ~3Form-C~3Form-C~3Form-A
~4 Form-A ~4Form-C~4Form-C~4Form-A
~5 Form-A ~5a, ~5c 2 Inputs ~5Form-C~5a, ~5c 2 Inputs
~6 Form-A ~6a, ~6c 2 Inputs ~6Form-C~6a, ~6c 2 Inputs
~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs
~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs
~6U module ~6V module ~67 module ~4A module
Terminal
assignment
Output or
input
Terminal
assignment
Output or
input
Terminal
assignment
Output Terminal
assignment
Output
~1 Form-A ~1 Form-A ~1Form-A~1 Not Used
~2 Form-A ~2 Form-A ~2Form-A~2 Solid-State
~3 Form-A ~3 Form-C ~3Form-A~3 Not Used
~4 Form-A ~4 2 Outputs ~4Form-A~4 Solid-State
~5 Form-A ~5a, ~5c 2 Inputs ~5Form-A~5 Not Used
~6 Form-A ~6a, ~6c 2 Inputs ~6Form-A~6 Solid-State
~7a, ~7c 2 Inputs ~7a, ~7c 2 Inputs ~7Form-A~7 Not Used
~8a, ~8c 2 Inputs ~8a, ~8c 2 Inputs ~8Form-A~8 Solid-State
~4B module ~4C module ~4D module ~4L module
Terminal
assignment
Output Terminal
assignment
Output Terminal
assignment
Output Terminal
assignment
Output
~1Not Used~1 Not Used ~1a, ~1c 2 Inputs ~1 2 Outputs
~2 Solid-State ~2 Solid-State ~2a, ~2c 2 Inputs ~2 2 Outputs
~3Not Used~3 Not Used ~3a, ~3c 2 Inputs ~3 2 Outputs
~4 Solid-State ~4 Solid-State ~4a, ~4c 2 Inputs ~4 2 Outputs
~
5Not Used~5 Not Used ~5a, ~5c 2 Inputs ~5 2 Outputs
~6 Solid-State ~6 Solid-State ~6a, ~6c 2 Inputs ~6 2 Outputs
~7Not Used~7 Not Used ~7a, ~7c 2 Inputs ~72 Outputs
~8 Solid-State ~8 Solid-State ~8a, ~8c 2 Inputs ~8 Not Used
