GE L90

APPENDIX D: MISCELLANEOUS REVISION HISTORY
L90 LINE CURRENT DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL D-3
D
Table D-2: Major changes for L90 manual version AF1 (English)
Table D-3: Major changes for L90 manual version AE3 (English)
1601-0081-AB2 7.3x 1 September 2015 15-2215
1601-0081-AC1 7.40x 8 December 2016 16-3319
1601-0081-AE1 7.41x 31 January 2017 17-3427
1601-0081-AE3 7.4x 28 April 2017 17-3561
1601-0081-AF1 7.6x 30 June 2017 17-3779
Page Description
--- General revision
--- Updated "faceplate" to "front panel" for consistency and to reflect web site
--- Added graphical front panel option to order codes and specifications in chapter 2, Interfaces chapter 4, Settings chapter 5,
Actual Values chapter 6
--- Added PEAP-GTC and PAP protocols for authenticating user logins when using a RADIUS server. Added to Settings > Product
Setup > Security > RADIUS Authentication Method and to Modbus memory map and F codes.
--- Updated Contact Inputs from 96 to 120 and Contact Outputs from 64 to 72 in Product Description in chapter 2 and FlexLogic
operands table in chapter 5
--- Updated Neutral Time Overcurrent element number from 4 to 6 in FlexLogic operands table, settings, features per product
table, Modbus memory map
--- Updated Phase Time Overcurrent element number from 4 to 6 in FlexLogic operands table, settings, features per product
table, Modbus memory map
--- Updated Breaker Restrike number from 4 to 2 in specifications, FlexLogic operands table, settings, features per product table,
Modbus memory map
--- Updated Current CT Settings number from 4 to 6 in FlexLogic operands table, settings, features per product table, and
Modbus memory map
--- Updated Ground Instantaneous number from 8 to 12 in FlexLogic operands table, settings, features per product table,
Modbus memory map
--- Updated Ground Time Overcurrent number from 4 to 6 in FlexLogic operands table, settings, features per product table,
Modbus memory map
--- Updated Phase Instantaneous Overcurrent number from 8 to 12 in FlexLogic operands table, settings, features per product
table, Modbus memory map
--- Updated Neutral Instantaneous Overcurrent from 8 to 12 in FlexLogic operands table, settings, features per product table,
Modbus memory map
3-35 Updated RS422 and Fiber Interface Connection figure for the clock channels (from 7a and 7b to 1a and 1b)
3-66 Added Connect to a D400 Gateway section
4-43 Updated LED Labelling instructions for the new Front Panel Label Designer
4-50 Added Standard Front Panel section for labelling LEDs and pushbuttons
5-105 Added USB Port section to enable/disable the USB port on the graphical front panel
5-125 Updated User-programmable Pushbuttons section as per specifications
5-147 Updated Breakers section as per specifications
5-152 Updated Disconnect Switches section as per specifications
11-5 Added Convert Device Settings section
11-7 Added Copy Settings to Other Device section
11-15 Added Replace Front Panel section for retrofit with the new graphical front panel
Page Description
--- General revision
2- Updated order codes
5-153 Updated PMU Basic Configuration settings
Manual P/N L90 revision Release date ECO
