General requirements
LOGIQ e – Basic Service Manual 2-5
5461614-100 English Rev. 6
Environmental specifications (continued)
NOTE: Temperature in degrees Celsius (ºC) conversion to
degrees F (ºF): (ºF) = (ºC * 9/5) + 32
Lighting
Bright light is needed for Ultrasound system installation, updates
and repairs. However, operator and patient comfort may be
optimized if the room light is subdued and indirect. Therefore a
combination lighting system (dim/bright) is recommended. Keep
in mind that lighting controls and dimmers can be a source of
EMI which could degrade image quality. These controls should
be selected to minimize possible interference.
Table 2-4: Environmental Requirements for an Ultrasound Room for Docking Cart
Item Values
Power Source Refer to Table 2-6 on page 2-8.
Power Rating 500VA (100V-120V); 500VA (220-240V)
Radiation Shielding NONE REQUIRED for ULTRASOUND ENERGY
Floor Landing
Approximately 680 - 800 kg/m
2
without Accessories
Floor Condition Gradient: WITHIN 5 degrees
Weight 53 kg without Accessories
CAUTION
Ensure that the probe face temperature does not exceed the
normal operation temperature range.
CAUTION
The LOGIQ e system and probe connector is not waterproof.
Do not expose the device to water or any kind of liquid.
