5-18 MAC 1200/1200 ST Revision C
2012250-021
Automatic Mode Recording: ECG Transmission
You must select one of these choices to clear the transmission error
message from the display.
127(
Unsuccessful transmission does not remove/delete the ECG
record from the local database.
Receiving Data with the CSI Communication Protocol
See Chapter 14, “Technical Specifications” for additional information.
Receiving ECGs is only possible with MAC 1200/1200 ST units. The
units must be in the Automatic mode.
1. Use the key combination and to display the screen for
receiving ECGs. The connected modem is automatically initialized.
The procedure can be aborted with .
2. Press to enable the receive data mode. The procedure can be
aborted with .
3. When you have enabled the receive data mode, the standard screen
display of the Automatic mode displays. The message Auto (REC)
indicates that the unit is ready to receive data.
ECGs can be recorded in the Automatic mode even while the unit is
in the receive data mode.
4. A message displays on the screen when the unit is receiving data.
The reception of data can be aborted with .
5. The ECG which has just been received is processed for the printout.
The report is printed in the selected format. Multiple ECGs are
received and printed one after the other.
After printout of the last ECG, the receive data mode is automatically
disabled. The mode is also disabled when you select another
operating mode.
The following information is annotated in the bottom line of each
report.
Sender
Software version and analysis program version used at the
sending unit (e.g. ACQ-DEV: V5.1M12i HEART V5.1)
