7-10 MIB High Impedance Bus Differntial Relay GEK-106426B
7.4 OPERATIONS 7 KEYPAD AND DISPLAY
7
MENU
ENTER
ESC
MIB
ADVANCED SETTINGS
ENTER
ESC
ADVANCED SETTINGS
GENERAL ADVANCED
ENTER
ESC
ENTER
ESC
ADVANCED SETTINGS
87 1 Function Group 2
GENERAL ADVANCED
Settings Group 1-2
Trip Min Time 50-300
87 1 Enable Yes-No
87 1 Trip Enable Yes-No
87 1 Pickup Level 0.005-0.4
87 1 Time Delay 0-600
ENTER
ESC
ADVANCED SETTINGS
87 2 Function Group 2
87 2 Enable Yes-No
87 2 Trip Enable Yes-No
87 2 Pickup Level 0.005-0.4
87 2 Time Delay 0-600
