GEK-106426B MIB High Impedance Bus Differntial Relay 4-5
4 COMMUNICATIONS 4.2 FILE
4
4.2.6 PRINT SETUP
The File – Print Setup option enables the user to configure the print setup for the settings file as shown in Figure 4–4:
Figure 4–4: PRINTER SETUP
4.2.7 PRINT PREVIEW
The File – Print Preview option displays a preview of the the settings print-out. It is also provides a quick view of all the
relay settings at a glance, without having to navigate through the different menu trees. From this screen it is also possible
to configure the printer that will be used, or to directly print the document. Double clicking on the document with the left
mouse button will enlarge the document view, and double clicking with the right button will reduce the size.
The available actions in this screen are shown in Figure 4–5::
Figure 4–5: PRINT PREVIEW CONTROLS
To Next Page
