GEK-106426B MIB High Impedance Bus Differntial Relay A-11
APPENDIX A A.4 WRITING SETTINGS
A
A.4.3 EXAMPLE OF SETTING CHANGE
This example modifies the IDENTIFICATION setting of an MIB module that stores this information at position 0134H of its
memory map. The module identification in an ASCII text of 16 characters.
SELECTION:
Request:
Reply:
SETTING CHANGE
Request:
Data0 => 5445 ("T""E") Data4 => 00xx (00 = End of the chain. The remaining characters are
not considered
Data1 => 5354 ("S""T") Data5 => xxxx
Data2 => 494E ("I""N") Data6 => xxxx
Data3 => 4700 ("G"-00) (00 = End of string Data7 => xxxx
Reply:
ADDRESS FUNCTION BEGINNING #REGS BYTES DATA0 CRC
01H 10H 0000H 0001H 02H 0100H A7C0H
ADDRESS FUNCTION BEGINNING #REGS CRC
01H 10H 0000H 0001H 01C9H
ADDRESS FUNCTION BEGINNING #REGS #BYTES
01H 10H 0128H 0008H 10H
ADDRESS FUNCTION BEGINNING #REGS #BYTES
01 10 0134 0008 10
DATA0 DATA1 DATA2 DATA3 DATA4 DATA5 DATA6 DATA7 CRC
5445 5356H 494E 4700 0000 0000 0000 0000 5361
ADDRESS FUNCTION BEGINNING #REGS CRC
01 10 0118 0008 4034
