8 RELAY COMMISSIONING 8.17 ADVANCED SETTINGS
8
8.17ADVANCED SETTINGS.
ENERVISTA MIIPC USER VALUE RANGE
Phase A 87 1 Pickup Phase A 87 1 Pickup Y/N
Phase B 87 1 Pickup Phase B 87 1 Pickup Y/N
Phase C 87 1 Pickup Phase C 87 1 Pickup Y/N
87 1 Pickup 87 1 Pickup Y/N
Phase A 87 2 Pickup Phase A 87 2 Pickup Y/N
Phase B 87 2 Pickup Phase B 87 2 Pickup Y/N
Phase C 87 2 Pickup Phase C 87 2 Pickup Y/N
87 2 Pickup 87 2 Pickup Y/N
General Pickup General Pickup Y/N
Phase A 87 1 Trip Phase A 87 1 Trip Y/N
Phase B 87 1 Trip Phase B 87 1 Trip Y/N
Phase C 87 1 Trip Phase C 87 1 Trip Y/N
87 1 Trip 87 1 Trip Y/N
Phase A 87 2 Trip Phase A 87 2 Trip Y/N
Phase B 87 2 Trip Phase B 87 2 Trip Y/N
Phase C 87 2 Trip Phase C 87 2 Trip Y/N
87 2 Trip 87 2 Trip Y/N
General trip General trip Y/N
87 1 Disable by input 87 1 Disable by input Y/N
87 2 Disable by input 87 2 Disable by input Y/N
General Trip enable/disable by digital input Trip disabled (by DI) Y/N
Protection status: in service/out of service Protection status Y/N
Digital output1 active/non active Output 1 Y/N
Digital output 2 active/non active Output 2 Y/N
Digital output 3 active/non active Output 3 Y/N
Digital output 4 active/non active Output 4 Y/N
Digital input 1 active/non active Digital input 1 Y/N
Digital input 2 active/non active Digital input 2 Y/N
Settings change disabled by digital input Sett. change disable Y/N
Trip operation by digital input Trip operation by input Y/N
Trip operation by command Trip operation by command Y/N
Auxiliary digital output latch reset Reset latch aux Y/N
Group 2 selection by digital input Settings group change Y/N
Oscillo trigger by digital input Oscillo trigg by DI Y/N
86 Status 86 Status
Reset 86 Reset 86
Oscillo trigger by command Oscillo trigg by comm Y/N
Settings change Settings change Y/N
EEPROM Failure EEPROM Failure Y/N
User settings/Factory settings User settings Y/N
