GE Multilin MIB - User Settings; Main Settings

GEK-106426B MIB High Impedance Bus Differntial Relay 8-17
8 RELAY COMMISSIONING 8.16 USER SETTINGS
8
8.16USER SETTINGS
The following pages intend to be useful to register the user settings. They can be used as a guide or template or to record
the relay settings, in case your company does not provide a proprietary form sheet.
8.16.1 MAIN SETTINGS
8.16.1.1 GENERAL SETTINGS
8.16.1.2 DIFFERENTIAL CURRENT UNITS
8.16.2 ADVANCED SETTINGS
8.16.2.1 ADVANCED GENERAL SETTINGS
ENERVISTA MIIPC HMI USER VALUE RANGE STEP
GENERAL SETTINGS PRODUCT SETUP GENERAL
Relay Status Relay Operation STA RDY / DIS NA
Frequency Frequency FRQ 50/60 Hz NA
Password --- PWD 1 – 255
Address --- ADD 1 – 255 1
Communications Speed --- BAUD
300, 600, 1200, 2400,
4800, 9600, 19200
NA
ENERVISTA MIIPC HMI USER VALUE RANGE STEP
FIRST LEVEL
DIFFERENTIAL
FUNCTION
87 1 FUNCTION F 87 1
First Level 87 Enable 87 1 Enable ENABLE 87 1 Y/N NA
Permission to Trip First
Level 87
87 1 Trip Enable TRIP 87 1 Y/N NA
First Level 87 Tap /
Pickup Value
87 1 Pickup Level TAP 87 1 0.005-0.04 A 0.01 A
First Level 87 Definite
Time Delay
87 1 Time Delay TIME 87 1 0 – 600.00 s. 0.01 s.
SECOND LEVEL
DIFFERENTIAL
FUNCTION
87 2 FUNCTION F 87 2
Second Level 87 Enable 87 2 Enable ENABLE 87 2 Y/N NA
Permission to Trip
Second Level 87
87 2 Trip Enable TRIP 87 2 Y/N NA
Second Level 87 Tap /
Pickup Value
87 2 Pickup Level TAP 87 2 0.005-0.04 A 0.01 A
Second Level 87 Definite
Time Delay
87 2 Time Delay TIME 87 2 0 – 600.00 s. 0.01 s.
ENERVISTA MIIPC HMI USER VALUE RANGE STEP
General Settings (Adv.) ADV. GENERAL SETT.
GENERAL
ADVANCED
Identification IDENTIFICATION --- Text NA
Active Settings group Settings Group TAB 1 – 2 NA
Trip Contact - Minimum time
closed.
Trip Min Time TRIP MIN TIME 50 – 300 ms. 1 ms.
