6-4 MIB High Impedance Bus Differntial Relay GEK-106426B
6.1 INPUT CONFIGURATION 6 I/0 CONFIGURATION
6
6.1.2 INPUT ELEMENTS
The following table shows the list of elements that can be assigned to each input. The table is divided into groups
GROUP ENERVISTA MII SETUP FUNCIONALITY
No Definition Input not assigned
MASK ED 1
87 1 Disable by Input Disable the operation (trip) of the 87 1 function
87 2 Disable by Input Disable the operation (trip) of the 87 1 function
MASK ED 2
DI all functions disable Disable the operation (trip) of every function
Trip Disable (by DI) Disable the operation of the trip contact
INPUTS
86B Input ‘B’ type contact of the latching relay
86A Input ‘A’ type contact of the latching relay
Trip Contact Close (PULSE) Activates trip contact
Group Change If the input is activated the active settings group will be group 2. If it is not activated, the
active settings group will be the adjusted in General Advanced Settings
Sett. Change disable Activated, it disables the possibility that settings and active group be changed: switching
to group 2 will only be possible through digital input Group change
Reset (PULSE) LEDs and latched auxiliary outputs reset
Oscillo Trigger (PULSE) Start oscillography storage
General Input Generic element that may be used in logic configuration.
