GE Multilin MIB - Zoom Pkt14.4

GEK-106426A MIB High Impedance Bus Differntial Relay B-5
APPENDIX B B.3 SAMPLES OF SETTINGS FOR PARTICULAR MODEMS
B
B.3.2 ZOOM PKT14.4
Initiation commands for the PC modem:
Commands:
B0 E0 L1 M1 N1 Q0 T V0 W0 X1 Y0
&C1&D2&G0&J0&K3&Q5&R1&S0&T5&X0&Y0
S Registers:
Initiation commands for the RELAY modem:
Commands:
B1 E0 L1 M1 N1 Q0 T V0 W0 X4 Y0
&C1 &D3 &G0 &J0 &K0 &Q5 &R1 &S1 &T4 &X0 &Y0
S Registers:
S00:001 S01:000 S02:043 S03:013 S04:010 S05:008 S06:002 S07:050 S08:002 S09:006
S10:014 S11:095 S12:050 S18:000 S25:005 S26:001 S36:007 S37:000 S38:020 S44:020
S46:138 S48:007 S95:000
S00:001 S01:000 S02:043 S03:013 S04:010 S05:008 S06:002 S07:050 S08:002 S09:006
S10:014 S11:095 S12:050 S18:000 S25:005 S26:001 S36:007 S37:000 S38:020 S44:020
S46:138 S48:007 S95:000
