5.3.6 EVENTS AND OSCILLOGRAPHY MASKS
Event masks have two possible settings, YES or NO. If an action (e.g. the trip of a protection function) is set as
YES, when the trip takes place an event will be generated. If it is set as NO, no event will be generated.
EVENT ENERVISTA MII SETUP DEFAULT RANGE STEP
Phase A 87 1 Pickup Phase A 87 1 Pickup YES Y/N NA
Phase B 87 1 Pickup Phase B 87 1 Pickup YES Y/N NA
Phase C 87 1 Pickup Phase C 87 1 Pickup YES Y/N NA
87 1 Pickup 87 1 Pickup YES Y/N NA
Phase A 87 2 Pickup Phase A 87 2 Pickup YES Y/N NA
Phase B 87 2 Pickup Phase B 87 2 Pickup YES Y/N NA
Phase C 87 2 Pickup Phase C 87 2 Pickup YES Y/N NA
87 2 Pickup 87 2 Pickup YES Y/N NA
General Pickup General Pickup YES Y/N NA
Phase A 87 1 Trip Phase A 87 1 Trip YES Y/N NA
Phase B 87 1 Trip Phase B 87 1 Trip YES Y/N NA
Phase C 87 1 Trip Phase C 87 1 Trip YES Y/N NA
87 1 Trip 87 1 Trip YES Y/N NA
Phase A 87 2 Trip Phase A 87 2 Trip YES Y/N NA
Phase B 87 2 Trip Phase B 87 2 Trip YES Y/N NA
Phase C 87 2 Trip Phase C 87 2 Trip YES Y/N NA
87 2 Trip 87 2 Trip YES Y/N NA
General trip General trip YES Y/N NA
87 1 Disable by input 87 1 Disable by input YES Y/N NA
87 2 Disable by input 87 2 Disable by input YES Y/N NA
General Trip enable/disable by digital input Trip disabled(by DI) YES Y/N NA
Protection status: in service/out of service Protection status YES Y/N NA
Digital output1 active/non active Output 1 YES Y/N NA
Digital output 2 active/non active Output 2 YES Y/N NA
Digital output 3 active/non active Output 3 YES Y/N NA
Digital output 4 active/non active Output 4 YES Y/N NA
Digital input 1 active/non active Digital input 1 YES Y/N NA
Digital input 2 active/non active Digital input 2 YES Y/N NA
Settings change disabled by digital input Sett. change disable YES Y/N NA
Trip operation by digital input Trip operation by input YES Y/N NA
Trip operation by command Trip operation by command YES Y/N NA
Auxiliary digital output latch reset Reset latch aux YES Y/N NA
Group 2 selection by digital input Settings group change YES Y/N NA
Oscillo trigger by digital input Oscillo trigg by DI YES Y/N NA
86 Status 86 Status YES Y/N NA
Reset 86 Reset 86 YES Y/N NA
Oscillography trigger by command Oscillo trigg by comm YES Y/N NA
Settings change Settings change YES Y/N NA
EEPROM Failure EEPROM Failure YES Y/N NA
User settings/Factory settings User settings YES Y/N NA
