GEK-106426B MIB High Impedance Bus Differntial Relay 3-7
3 HARDWARE 3.3 WIRING
3
3.3.2 CONTROL POWER
CAUTION: CONTROL POWER SUPPLIED TO THE RELAY MUST MATCH THE RATED VOLTAGE OF THE RELAY. IF
THE VOLTAGE IS APPLIED TO THE WRONG TERMINALS, DAMAGE MAY OCCUR.
Table 3–1: CONTROL POWER VOLTAGE RANGE
RANGE OPERATION RANGE
LO 38.4-57.6 Vdc
HI 100-150 Vdc
