B-4 MIB High Impedance Bus Differntial Relay GEK-106426A
B.3 SAMPLES OF SETTINGS FOR PARTICULAR MODEMS APPENDIX B
B
B.3SAMPLES OF SETTINGS FOR PARTICULAR MODEMS
In the following sections, we will detail some communications parameters, already tested for the following modems.
B.3.1 SPORTSTER FLASH X2 MODEM (HAYES)
Initiation commands for the modem on the PC side:
We will add the following commands to the default configuration:
Initiation commands for the modem on the RELAY side :
The following options must be added to the default configuration:
&AnEnable/disable the ARQ result codes Disable the ARQ result codes &A0
&HnSets the flux control for the data transfer (TD). Flux control disabled &H0
&InSets the software flux control for the data reception
(RD).
Software flux control disabled. &I0
&KnEnable/Disable data compression Data compression disabled &K0
&MnSets the error control (ARQ) for 1200 bps and higher. Normal mode, error control disabled &M0
&RnConfigures the hardware flux control for data
reception (DR) and transfer request (RTS)
Modem ignores RTS. &R1
S15Record with bit representation. Disable ARQ/MNP for V.32/V.32bis. S15=4
S32Record with bit representation. Disable V.34. modulation S32=8
&AnEnable/disable the ARQ result codes ARQ result codes are disabled &A0
&DnControl the DTR operations About DTR control. &D0
&HnSets the flux control for the data transfer (TD). Flux control disabled &H0
&InSets the software flux control for the data reception
(RD).
Software flux control disabled. &I0
&KnEnable/Disable data compression Data compression disabled &K0
&MnSets the error control (ARQ) for 1200 bps and higher. Normal mode, error control disabled &M0
&RnConfigures the hardware flux control for data
reception (DR) and transfer request (RTS)
Modem ignores RTS. &R1
S0Sets the number of rings necessary for answering in
automatic answering mode
The modem will answer to the first ring. S0=1
S15Record with bit representation. Disable ARQ/MNP for V.32/V.32bis. S15=4
S32Record with bit representation. Disable V.34. modulation S32=8
