A-6 MIB High Impedance Bus Differntial Relay GEK-106426B
A.2 COMMAND EXECUTION APPENDIX A
A
A.2.2 EXAMPLE
A.2.2.1 SELECTION
Request:
To activate Group 2, the selection command will be 0FH; therefore the operation to be performed is a writing of word 0F
00H at the address 00 00H.
Request:
Reply:
A.2.2.2 CONFIRMATION
The operation confirmation code for Group 2 activation is 16 (10h). In this case, it is necessary to send the
relay password (in this example its value is 1)
Request:
Reply:
ADDRESS FUNCTION BEGINNING #REGS #BYTES DATA0 CRC
01H 10H 0000H 0001H 02H 0F00H A3A0H
ADDRESS FUNCTION BEGINNING #REGS CRC
01H 10H 0000H 0001H 01C9H
ADDRESS FUNCTION BEGINNING #REGS #BYTES DATA0 DATA1 DATA2 CRC
01H 10H 0000H 0003H 06H 10 00H 01 00H 00 00H E5ECH
ADDRESS FUNCTION BEGINNING #REGS CRC
01H 10H 0000H 0003H 8008H
