A-16 MIB High Impedance Bus Differntial Relay GEK-106426B
A.5 EVENTS APPENDIX A
A
The following information is supplied for each event:
NAME BIT NUMBER RECORD
INDEX
NUMBER OF
BYTES
FORMAT
Event code 0 0 2 F5
Date & Time 16 1 6 F1
Idiff phase A 64 4 4 F2
Idiff phase B 96 6 4 F2
Idiff phase C 128 8 4 F2
Trip operation by communications 160 10 2 F4
LEDs and latched outputs reset 161 10 2 F4
Reset 86 170 10 2 F4
Protection status (0=out of service, 1=In service) 185 11 2 F4
Output 1 186 11 2 F4
Output 2 187 11 2 F4
Output 3 188 11 2 F4
Output 4 189 11 2 F4
Input 1 190 11 2 F4
Input 2 191 11 2 F4
Settings change inhibition by DI 193 12 2 F4
Trip operation by DI 194 12 2 F4
Settings group change by DI 198 12 2 F4
Oscillo trigger by DI 199 12 2 F4
86 Status 201 12 2 F4
Oscillo trigger by communications 202 12 2 F4
Setting change 205 12 2 F4
EEPROM error 206 12 2 F4
User settings (0 factory default, 1 when the first change
is made to any setting)
207 12 2 F4
Pickup 87 1_A 208 13 2 F4
Pickup 87 1_B 209 13 2 F4
Pickup 87 1_C 210 13 2 F4
Pickup 87 1 211 13 2 F4
Pickup 87 2_A 212 13 2 F4
Pickup 87 2_B 213 13 2 F4
Pickup 87 2_C 214 13 2 F4
Pickup 87 2 215 13 2 F4
General Pickup 223 13 2 F4
87 1 inhibition by DI 227 14 2 F4
87 2 inhibition by DI 231 14 2 F4
General inhibition by DI 239 14 2 F4
Trip 87 1_A 240 15 2 F4
Trip 87 1_B 241 15 2 F4
Trip 87 1_C 242 15 2 F4
Trip 87 1 243 15 2 F4
Trip 87 2_A 244 15 2 F4
Trip 87 2_B 245 15 2 F4
Trip 87 2_C 246 15 2 F4
Trip 87 2 247 15 2 F4
General Trip 256 15 2 F4
