Chapter 2
.
C
PU Features
& Specif
ications
52
PACSystems* RX7i, RX3i and RSTi-EP CPU Reference Manual
GFK
-2222AD
Ethernet Indicators (EFA RJ45 Built-in LEDs)
Two
LEDs
are
integrated
into
the EFA
RJ45
connector.
These
LEDs
indicate th
e lin
k status
and
link
speed,
as follows:
LED
LED State
Operating State
Link
Status
(upper)
On Green
The corresponding link
has been es
tablished.
Blinking
Green
Traffic is detect
ed at the corresp
onding port.
Off
No connection establ
ished at corresponding port.
Link
Speed
(lower)
On Green
Corresponding n
etwork da
ta speed is 1 Gbps.
On Yellow
EFA port only: Corre
sponding n
etwork data speed is 1
00 Mbps
Off
Corresponding n
etwork da
ta speed is 10 Mbps
62
64
