Rev. 00 02/21
18
Product description OptiCenter OC09
Dimensions
OptiCenter OC09
24 guns
Area*
(width x depth) (mm)
1900 x 1700
Overall height (mm)
2100 (2250 - OptiFeed
connection)
Weight (kg)
OptiCenter base weight
460
loaded*
765
* with electrostatic and system control
Sound pressure level
OptiCenter OC09
Normal operation
75 dB(A)
Cleaning operation mode
for a short time up to
95 dB(A)
The sound pressure level was measured while the unit was in operation;
measurements were taken at the most frequent operator positions and at
a height of 1.7 m from the ground.
The specified value is applicable only for this product itself and does not
take into account external noise sources or cleaning impulses.
The sound pressure level may vary, depending on the product
configuration and space constraints.
Rating plate
Fig.
3
: Rating plate
Fields with a gray background contain contract-specific data!
