Gema OptiStar CG06 - CG06 Inside Rear Wall Spare Parts; Spare Parts for CG06 Inside Rear Wall

V 09/18
OptiStar CG06 Automatic gun control unit Spare parts list • 65
OptiStar CG06 Automatic gun control unit - inside rear
wall
1
Pneumatic group - complete
1005 922
2
Valve cable - CG06
1001 410
3 Washer - Ø 6.4/12.5x1.6 mm 1001 686
4
Lock washer - M3 R
201 880
5 Hexagon nut - M3 202 142
6 Cylinder screw - M3x16 mm 221 074
7 Hexagon screw - M6x30 mm 215 279
8
Fluidizing pad - 1/8"a
237 264
9
Screw-in nipple - 1/8"a, Ø 6 mm
262 315
10
Throttle motor - complete
1000 064
OptiStar CG06 Automatic gun control unit - inside rear wall
1
2
8
4 6 5
3
7
9
10
