68 • Spare parts list OptiStar CG06 Automatic gun control unit
OptiStar CG06-C - outside rear wall
1 Rear wall (aluminum) 1000 070
Rear wall (steel sheet) 1005 099
2 Cap screw - M3x10 mm 216 739
3 Washer - Ø 6.4/12.5x1.6 mm 1001 686
4 Cap screw - M6x10 mm 205 214
5 Lock nut - M18x0.75 mm 1001 799
6 Screw plug - complete 1001 789
7 Rectus quick release connection - complete (aluminum rear wall) 1001 517
Rectus quick release connection - complete (steel sheet rear wall) 1004 181
8 Mains connection CG06 1001 176
9 Cap screw - M3x8 mm 202 363
10 Gun connection CG06 1001 179
11 Washer - Ø 6.4/12.5x1.6 mm 200 476
12 Hexagon nut - M6 200 417
13 Shake proof washer - A type, M6 200 450
14 Milled nut - M6 200 433
15 Hose connection - complete, Ø 8/6 mm (aluminum rear wall) 1001 519
Hose connection - complete, Ø 8/6 mm (steel sheet rear wall) 1004 183
Protection cap for 2.2 Aux connector socket (not shown) 206 474
OptiStar CG06-C - outside rear wall
2
8
5
6
7
3
1
4
9
10
14
13
12
11
15
