111
04
word
4
I in S phase
input current
0.1A
2
05
word
4
I in T phase
input current
0.1A
2
06
word
4
F input frequency
0.1Hz
2
07
word
4
U out R phase
output voltage
0.1 Volt
2
08
word
4
U out S phase
output voltage
0.1 Volt
2
09
word
4
U out T phase
output voltage
0.1 Volt
2
10
word
4
I out R phase
output current
0.1A
2
11
word
4
I out S phase
output current
0.1A
2
12
word
4
I out T phase
output current
0.1A
2
13
word
4
P out
output power
0.1kVA
2
14
word
4
P out
output power
0.1kW
2
15
word
4
PF
output power factor
0.01Cos
2
16
word
4
U Bypass
R phase voltage
0.1 Volt
2
17
word
4
U Bypass
S phase voltage
0.1 Volt
2
18
word
4
U Bypass
T phase voltage
0.1 Volt
19
word
4
F out
output frequency
0.1Hz
20
word
4
U Bat
battery voltage
0.1 Volt
21
word
4
I charch Bat
battery charging/discharging
0.1A
22
word
4
Temp 1
battery temperature
0.1degC
23
word
4
Temp 2
battery temperature
0.1degC
24
word
4
Temp 3
battery temperature
0.1degC
25
word
4
Temp 4
battery temperature
0.1degC
26
word
4
Temp 5
UPS shelf temperature
0.1degC
Digital output (DO)
Function 1 to read data; 5 to control the function
0
bit
1 / 5
UPS Turn On
1
bit
1 / 5
UPS Shut down
2
bit
1 / 5
Alarm Reset
3
bit
1 / 5
Battery Instant Charging
4
bit
1 / 5
Battery Floating Charging
5~10
bit
For future expansion
After
Vender self definition
