Generex CS121BL - Pin Layout of Input-Sockets of the SENSORMANAGER Unit

122
POWER
Configurated UPS Power
LOAD
Configurated Load
HOLDTIME
Configurated hold time
RECHARGETIME
Configurated time for a complete battery charging
MODEL
UPS model name
TIMEREMAIN
Resttime (AUTONOMTIME-POWERREMAIN)
LOCALTIME
Local timestamp
OUTPHASES
Output phase
INPHASES
Input phase
LOCATION
UPS-Adapter location
DATE
Date
TIME
Time
ATTACHED_DEVICES
Attached devices
BATTINSTDATE
Battery installation date
AGENTSOFTREV
Firmware version
MANUFACTURER
Manufacturer
TEMP1,
…,
TEMP8
Actual measurement for sensors 1-8, used for SensorMan settings
only
TEMP1LOCATION,
…,
TEMP8LOCATION
Configurated sensor 1-8 location
TEMP1UNIT,
…,
TEMP8UNIT
Configurated sensor 1-8 unit
CUSTOM1TEXT,
…,
CUSTOM6TEXT
Configurated Custom Text 1-6
F. Pin layout of Input-sockets of the SENSORMANAGER unit
INPUT 1:
Pin 1 Input Voltage 9-24Volt +
Pin 2 Analog Channel 1 (0-10V+)
Pin 3 Analog Channel 5 (0-10V+)
Pin 4 Ground
Pin 5 OUTPUT: Open collector OUT 9-24 V, max. 30mA
Pin 6 INPUT: Digital Input 9-24V
INPUT 2:
Pin 1 Input Voltage 9-24Volt +
Pin 2 Analog Channel 2 (0-10V+)
Pin 3 Analog Channel 6 (0-10V+)
Pin 4 Ground
Pin 5 OUTPUT: Open collector OUT 9-24 V, max. 30mA
Pin 6 INPUT: Digital Input 9-24V
