25
ReACT Pro
NITROXNITROX
SET FO2
Factory set for AIR, FO2 can also be set to values between 21 and 50% in increments of 1%.
• While viewing the Set 1 screen, press/release the A (left) button 2 times (< 2 sec each time),
the Set FO2 screen appears with the Set Point flashing (Fig. 15).
• Press/release the S (right) button repeatedly (< 2 sec each time) to increase the Set Point
from AIR to 21 up to 50% in increments of 1%, then display AIR again; or depress/hold the
S button to scroll upward through the Set Points at a rate of 8 per second from AIR to 21 up
to 50%, then AIR (stopping momentarily at 32%).
• For each FO2 value that appears, the Max Depth allowed for the PO2 alarm value set will
be displayed (Fig. 15a). If FO2 is set for AIR, no depth is displayed.
• Press/release the A button (< 2 sec) to accept the setting and access Set FO2 Default.
• Depress both buttons for 2 seconds to revert to the Surface Main.
SET FO2 50% DEFAULT
Factory set ON, the FO2 50% Default feature can be set to OFF.
• While viewing the Set 1 screen, press/release the A (left) button 3 times (< 2 sec each time),
the Set FO2 Default screen appears with the Set Point flashing (Fig. 16).
• Press/release the S (right) button (< 2 sec) to toggle the Set Point between ON and OFF.
• Press/release the A button (< 2 sec) to accept the setting and access Set Audible Alarm.
• Depress both buttons for 2 seconds to revert to the Surface Main.
AIRAIR
MAX
FT
NITROXNITROX
Fig. 15 - Set FO2
a
Fig. 16 - Set FO2 Default
