37
ReACT Pro
No decompression times are only displayed for depths where there are at least 3 minutes of dive
time available at the depth, taking into account a descent rate of 60 FPM (18 MPM). Depths
greater than the Max Depth that can be achieved with a PO2 = Set Point will not be displayed.
To access and view the Plan Mode while viewing the Surface Main screen:
• press/release the A (left) button 2 times
• press/release the S (right) button repeatedly (< 2 sec each time) to step upward through the
sequence of Depths from 30 to 190 FT (9 to 57 M) in 10 FT (3 M) increments
• depress both buttons simultaneously for 2 seconds to revert to the Surface Main
WARNING: If Wet Activation is set Off, the ReACT Pro must be manually
activated prior to start of a dive. Dive mode will not activate automatically
by immersion in water unless the Wet Activation feature is Set ON.
DIVE MODES
During dives, there is a Main screen that displays information most relevant for conditions at the
time. Other information can be viewed by temporarily accessing ALT screens.
During No Deco dives deeper than 80 FT (24 M), a Deep Stop (DS) to be taken at 1/2 Max Depth
for 2 minutes (2:00 min:sec) is triggered and displayed as a Preview screen when accessed while
10 FT (3 M) deeper than the calculated Stop Depth and as a Stop screen upon ascent to 10 FT (3
M) below the Stop Depth. When the feature is set OFF, the screen are not displayed.
During an Ascent on No Deco dives deeper than 30 FT (10 M), a Safety Stop to be taken at 20 FT
(6 M) for 3 minutes is displayed.
NDLs
for an Air Dive
(no dive made yet)
Depth NDL
FT (M) hr:min
30 (9) 4:20 (4:43)
40 (12) 2:17 (2:24)
50 (15) 1:21 (1:25)
60 (18) :57 (:59)
70 (21) :40 (:41)
80 (24) :30 (:32)
90 (27) :24 (:25)
100 (30) :19 (:20)
110 (33) :16 (:17)
120 (36) :13 (:14)
130 (39) :11 (:11)
140 (42) :09 (:09)
150 (45) :08 (:08)
160 (48) :07 (:07)
170 (51) :07 (:06)
180 (54) :06 (:06)
190 (57) :05 (:05)
