Genie Z Series User Manual

Maintenance Manual April 2018
Annual Maintenance Procedures
126 S
®
Booms • Z
®
Booms Part No. 1268489GT
8 Using a suitable lifting device, remove all test
weights from the platform.
Result: There is no audible alarm. The
platform overload indicator light should turn off
at the ground controls.
Note: There may be an 2 second delay before the
overload indicator lights and alarm turn off.
9 Start the engine and test all machine functions
from the ground controls.
Result: All ground control functions should
operate normally.
A-17
Test the Dual Capacity and
Platform Overload System - S-80
XC and S-85 XC Models
Genie specifications require that this procedure be
performed annually OR when the machine fails to
lift the maximum rated load.
Testing the platform overload system regularly is
essential to safe machine operation. Continued use
of an improperly operating platform overload
system could result in the system not sensing an
overloaded platform condition. Machine stability
could be compromised resulting in the machine
tipping over.
Note: Perform this procedure with the boom fully
retracted and in the stowed position and with the
machine on a firm, level surface.
restricted overload
1 Remove all weight, tools, accessories and
equipment from the platform.
Note: Failure to remove all weight, tools and
accessories from the platform will result in an
inaccurate test.
2 Turn the key switch to ground control and pull
out the red Emergency Stop button to the on
position at both ground and platform controls.

Genie Z Series Specifications

General

Lift Capacity	500 lb (227 kg) to 660 lb (300 kg)
Gradeability	30%
Power Source	Diesel, Electric
Capacity	500 lb (227 kg) to 1, 000 lb (454 kg)
Drive System	4-wheel drive
Tire Type	Solid
Steering	2-wheel or 4-wheel
